Infineon, Type N-Channel IGBT, 100 A 1200 V, 3-Pin TO-247, Through Hole
- RS Stock No.:
- 273-2974
- Mfr. Part No.:
- IKQ100N120CH7XKSA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 unit)*
£8.01
(exc. VAT)
£9.61
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £8.01 |
| 5 - 9 | £7.85 |
| 10 - 24 | £7.29 |
| 25 - 49 | £6.67 |
| 50 + | £6.15 |
*price indicative
- RS Stock No.:
- 273-2974
- Mfr. Part No.:
- IKQ100N120CH7XKSA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Product Type | IGBT | |
| Maximum Continuous Collector Current Ic | 100A | |
| Maximum Collector Emitter Voltage Vceo | 1200V | |
| Maximum Power Dissipation Pd | 361W | |
| Package Type | TO-247 | |
| Mount Type | Through Hole | |
| Channel Type | Type N | |
| Pin Count | 3 | |
| Switching Speed | 66ns | |
| Maximum Collector Emitter Saturation Voltage VceSAT | 2.15V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Gate Emitter Voltage VGEO | 20 V | |
| Maximum Operating Temperature | 175°C | |
| Standards/Approvals | RoHS, JEDEC47/20/22 | |
| Length | 20.9mm | |
| Series | TRENCHSTOP IGBT7 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Product Type IGBT | ||
Maximum Continuous Collector Current Ic 100A | ||
Maximum Collector Emitter Voltage Vceo 1200V | ||
Maximum Power Dissipation Pd 361W | ||
Package Type TO-247 | ||
Mount Type Through Hole | ||
Channel Type Type N | ||
Pin Count 3 | ||
Switching Speed 66ns | ||
Maximum Collector Emitter Saturation Voltage VceSAT 2.15V | ||
Minimum Operating Temperature -40°C | ||
Maximum Gate Emitter Voltage VGEO 20 V | ||
Maximum Operating Temperature 175°C | ||
Standards/Approvals RoHS, JEDEC47/20/22 | ||
Length 20.9mm | ||
Series TRENCHSTOP IGBT7 | ||
Automotive Standard No | ||
The Infineon IGBT7 H7 discrete in TO-247PLUS-3pin package has been developed to fulfill the demand in applications focusing on decarbonisation such as solar photovoltaic, uninterruptible power supplies and battery chargers.
Optimized performance in application conditions
Lowest conduction losses
Humidity robustness under harsh environment
Improved EMI performance
