Infineon IMBG120R350M1HXTMA1 IGBT Module, 4.7 A TO-263
- RS Stock No.:
- 258-3757
- Mfr. Part No.:
- IMBG120R350M1HXTMA1
- Brand:
- Infineon
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£3.84
(exc. VAT)
£4.61
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 650 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £3.84 |
| 10 - 24 | £3.42 |
| 25 - 49 | £3.23 |
| 50 - 99 | £3.00 |
| 100 + | £2.77 |
*price indicative
- RS Stock No.:
- 258-3757
- Mfr. Part No.:
- IMBG120R350M1HXTMA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Maximum Continuous Collector Current Ic | 4.7A | |
| Product Type | IGBT Module | |
| Maximum Power Dissipation Pd | 65W | |
| Package Type | TO-263 | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 175°C | |
| Standards/Approvals | JEDEC47/20/22 | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Maximum Continuous Collector Current Ic 4.7A | ||
Product Type IGBT Module | ||
Maximum Power Dissipation Pd 65W | ||
Package Type TO-263 | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 175°C | ||
Standards/Approvals JEDEC47/20/22 | ||
Automotive Standard No | ||
The Infineon CoolSiC1200 V, 350 mΩ SiC MOSFET in a D2PAK-7L package build on a state-of-the-art trench semiconductor process optimized to combine performance with reliability in operation. The low power losses of CoolSiC technology, combined with XT interconnection technology in a new 1200 V optimized SMD package, enables top efficiency and passive cooling potential in applications such as drives, chargers and industrial powers supplies.
Very low switching losses
Short-circuit withstand time, 3 μs
Fully controllable dV/dt
Efficiency improvement
Enabling higher frequency
Increased power density
