Siemens Switch Disconnector, 3-Pole, 32 A, 32A
- RS Stock No.:
- 212-5786
- Mfr. Part No.:
- 3LD2213-0TK51
- Brand:
- Siemens
Subtotal (1 unit)*
£54.19
(exc. VAT)
£65.03
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1 unit(s) ready to ship from another location
- Plus 5 unit(s) shipping from 19 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £54.19 |
*price indicative
- RS Stock No.:
- 212-5786
- Mfr. Part No.:
- 3LD2213-0TK51
- Brand:
- Siemens
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Siemens | |
| Number of Poles | 3 | |
| Product Type | Switch Disconnector | |
| Mount Type | Floor | |
| Switching Voltage | 690V | |
| Switching Current | 32A | |
| Terminal Type | Box | |
| Series | SENTRON | |
| IP Rating | IP65 | |
| Minimum Operating Temperature | -25°C | |
| Switching Power | 11.5kW | |
| Fuse Current | 32A | |
| Maximum Operating Temperature | 55°C | |
| Auxiliary Contacts Available | No | |
| Standards/Approvals | VDE, UL, CCC, EN, CSA, RoHS, CE | |
| Select all | ||
|---|---|---|
Brand Siemens | ||
Number of Poles 3 | ||
Product Type Switch Disconnector | ||
Mount Type Floor | ||
Switching Voltage 690V | ||
Switching Current 32A | ||
Terminal Type Box | ||
Series SENTRON | ||
IP Rating IP65 | ||
Minimum Operating Temperature -25°C | ||
Switching Power 11.5kW | ||
Fuse Current 32A | ||
Maximum Operating Temperature 55°C | ||
Auxiliary Contacts Available No | ||
Standards/Approvals VDE, UL, CCC, EN, CSA, RoHS, CE | ||
- COO (Country of Origin):
- DE
Siemens SENTRON Series Switch Disconnector, 32A Rated Current, 690V Insulation Voltage - 3LD2213-0TK51
This switch disconnector is a 3-pole floor-mounted main switch designed for isolation and fused protection in industrial installations. It provides manual rotary operation with a black short rotary knob and door coupling for built-in mounting. The unit operates across standard AC frequencies and is intended for use where secure, lockable disconnection and compatibility with upstream fusing are required.
Features and Benefits:
• 32A rated current delivers consistent operational capacity
• 11.5kW switching power supports moderate motor loads
• IP65 front protection enables use in dust- and water-prone areas
• -25°C to 55°C ambient range permits wide temperature deployment
• Box Terminal connection eases conductor termination and routing
• 11.5kW switching power supports moderate motor loads
• IP65 front protection enables use in dust- and water-prone areas
• -25°C to 55°C ambient range permits wide temperature deployment
• Box Terminal connection eases conductor termination and routing
Applications
• Suitable for isolation of three-phase distribution circuits
• Ideal for motor control panels requiring fused protection
• Used with gG fuses for short-circuit co-ordination up to 50kA
• Can be used in indoor and sheltered outdoor enclosures
• Appropriate for maintenance/repair isolation on heavy equipment
• Ideal for motor control panels requiring fused protection
• Used with gG fuses for short-circuit co-ordination up to 50kA
• Can be used in indoor and sheltered outdoor enclosures
• Appropriate for maintenance/repair isolation on heavy equipment
What mounting arrangements does it support?
It is a fixed unit for floor mounting with door coupling and 4-hole front fixing and also permits rail mounting.
Which conductor sizes can be connected to the main circuit?
Solid conductors from 1.5 to 16mm² and finely stranded with end processing up to 10mm² are supported.
How does it perform under short-circuit conditions?
With appropriate gG fuses it permits conditional short-circuit currents up to 50kA at 690V and limited let-through currents of 5kA for closed-switch combinations.
Are auxiliary contacts fitted as standard?
No auxiliary contacts are fitted
up to 3 NC and 5 NO contacts can be attached if required.
What approvals and ratings apply to its use?
It holds multiple approvals including VDE, UL, CCC, EN, CSA, RoHS and CE and meets NEMA ratings 1, 3R, 4X, 12.
