Panasonic PCB Mount Force Guided Relay, 5V dc Coil Voltage, 2 Pole, DPDT
- RS Stock No.:
- 528-4023
- Mfr. Part No.:
- SF2D-DC5V
- Brand:
- Panasonic
316 In stock - FREE next working day delivery available
Added
Price Each
£32.09
(exc. VAT)
£38.51
(inc. VAT)
| Units | Per unit |
| 1 + | £32.09 |
- RS Stock No.:
- 528-4023
- Mfr. Part No.:
- SF2D-DC5V
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CZ
Product Details
Force Guided Safety Relay - SF2 Series
Used in machines, apparatus or installations that need to meet special safety requirements (presses, combustion, railway, medical)
Maximum switching voltage: 400V
Operating temperature range: -40°C to +70°C
Contact material: AgSnO2 with Au flash
Operating temperature range: -40°C to +70°C
Contact material: AgSnO2 with Au flash
Standards
EN50205 Type A, IEC60664-1 III/4kV
Approvals
cUL, TUV, SEV
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 5V dc |
| Mounting Type | PCB Mount |
| Contact Configuration | DPDT |
| Number of Poles | 2 |
| Coil Resistance | 50Ω |
| Switching Current | 6A |
| Coil Power | 500mW |
| Maximum Switching Current AC | 6 A |
| Maximum Switching Current DC | 6 A |
| Maximum Switching Voltage DC | 30V |
| Maximum Switching Voltage AC | 440V |
| Terminal Type | Through Hole |
| Maximum Operating Temperature | +70°C |
| Series | SF2D |
| Minimum Operating Temperature | -40°C |
| Contact Material | Gold Plated |
| Maximum Switching Power DC | 180 W |
| Isolation Coil To Contact | 2.5kV rms |
| Height | 16mm |
| Depth | 25mm |
| Maximum Switching Power AC | 1.5 kVA |
| Life | 100000 (Electrical) cycles, 10000000 (Mechanical) cycles |
| Length | 53.3mm |
