Schneider Electric ClimaSys CV Series Filter Fan, 230V, AC, 170 m³/h Filtered, 170 m³/h Unimpeded, 119 mm, 119 mm x
- RS Stock No.:
- 177-9011
- Mfr. Part No.:
- NSYCVF170M230
- Brand:
- Schneider Electric
Subtotal (1 unit)*
£96.34
(exc. VAT)
£115.61
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 8 unit(s) shipping from 27 April 2026
- Plus 5 unit(s) shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £96.34 |
*price indicative
Better World
Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.
- RS Stock No.:
- 177-9011
- Mfr. Part No.:
- NSYCVF170M230
- Brand:
- Schneider Electric
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Schneider Electric | |
| Unimpeded Air Flow | 170m³/h | |
| Product Type | Filter Fan | |
| Noise Level | 41dB | |
| Filtered Air Flow | 170m³/h | |
| Input Power | 17W | |
| AC or DC Operation | AC | |
| Installation Depth | 38mm | |
| Supply Voltage | 230V | |
| Face Height | 119mm | |
| Face Width | 119mm | |
| Standards/Approvals | RoHS | |
| Better World Product | Yes | |
| Series | ClimaSys CV | |
| Configuration | Square | |
| Select all | ||
|---|---|---|
Brand Schneider Electric | ||
Unimpeded Air Flow 170m³/h | ||
Product Type Filter Fan | ||
Noise Level 41dB | ||
Filtered Air Flow 170m³/h | ||
Input Power 17W | ||
AC or DC Operation AC | ||
Installation Depth 38mm | ||
Supply Voltage 230V | ||
Face Height 119mm | ||
Face Width 119mm | ||
Standards/Approvals RoHS | ||
Better World Product Yes | ||
Series ClimaSys CV | ||
Configuration Square | ||
Schneider Electric Filter Fan
The Schneider Electric ClimaSys CV series filter fan is designed with optimised fins and blades to enable maximum airflow and low energy consumption. It is designed to maximise filter surface area, thus capturing and filtering more air. The flat structure minimises the protrusion of the fan from the surface of the enclosure wall. This new generation filter fan prevents dust and other contaminants from entering the enclosure through any unsealed opening. This efficient and economical filter fan enables optimum airflow and removes unwanted heat from the enclosure and maintains a safe temperature within the enclosure. All the Schneider Electric products are designed to sustain a long life. This fan is one of the many available configurations for indoor as well as outdoor use.
Features and Benefits
• Efficient filter power
• Long lasting
• Low energy consumption
• Low noise
• Space saver
• 2 protective grille on the front and rear surfaces
• Filtered air flow is 170 m³/h
Applications
• Factory
• Kitchen
• Steam room and bathroom
Certifications
• UL approved
