Belden 1633ENS Cat5e Ethernet Cable, 500 m, Screened, Grey, Low Smoke Zero Halogen
- RS Stock No.:
- 419-5405
- Distrelec Article No.:
- 301-85-687
- Mfr. Part No.:
- 1633ENS.00500
- Brand:
- Belden
Subtotal (1 reel of 500 metres)*
£863.05
(exc. VAT)
£1,035.66
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1 unit(s) shipping from 24 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £863.05 | £1.726 |
*price indicative
- RS Stock No.:
- 419-5405
- Distrelec Article No.:
- 301-85-687
- Mfr. Part No.:
- 1633ENS.00500
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Belden | |
| Product Type | Ethernet Cable | |
| Series | 1633ENS | |
| LAN Category | Cat5e | |
| Cable Length | 500m | |
| Shield Type | Shielded | |
| Screened/Unscreened | Screened | |
| Conductor Type | Solid | |
| Jacket Material | Low Smoke Zero Halogen | |
| Jacket Colour | Grey | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | ANSI/TIA/EIA 568, EN 50173-1 | |
| Core Strands | 1 x 24AWG | |
| Cable CSA | 0.2mm² | |
| Fire Behaviour | Low Smoke Zero Halogen (LSZH) | |
| Conductor Material | Copper | |
| Number of Strands | 1 | |
| Size of Strands | 24AWG | |
| Number of Cores | 8 | |
| Outside Diameter | 6.3mm | |
| Select all | ||
|---|---|---|
Brand Belden | ||
Product Type Ethernet Cable | ||
Series 1633ENS | ||
LAN Category Cat5e | ||
Cable Length 500m | ||
Shield Type Shielded | ||
Screened/Unscreened Screened | ||
Conductor Type Solid | ||
Jacket Material Low Smoke Zero Halogen | ||
Jacket Colour Grey | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals ANSI/TIA/EIA 568, EN 50173-1 | ||
Core Strands 1 x 24AWG | ||
Cable CSA 0.2mm² | ||
Fire Behaviour Low Smoke Zero Halogen (LSZH) | ||
Conductor Material Copper | ||
Number of Strands 1 | ||
Size of Strands 24AWG | ||
Number of Cores 8 | ||
Outside Diameter 6.3mm | ||
- COO (Country of Origin):
- HU
Belden Cat5e Ethernet Cable, 24AWG - 1633ENS
Use this Ethernet cable from Belden for high-speed data transmission in your network devices. This cable comes unterminated at both ends, giving you the freedom to cut and crimp it according to your needs. It has eight copper conductors that are twisted around each other to prevent electromagnetic interference (EMI). This means that you get noiseless signal transmission across your network. Thanks to the length of this cable you have enough for large-scale applications. You'll find general-purpose data cables like this one used in domestic, commercial and industrial environments.
Features & Benefits
• Outer sheath is LSZH (low-smoke zero-halogen), so it won't emit toxic fumes in the event of a fire
• Sheath is easy to strip, which reduces installation time and hand fatigue when preparing a large number of wires
• Wide operating temperature range of -30°C to +60°C for use in harsh conditions
Applications
• Building backbone cabling
• ATM (asynchronous transfer mode) systems
Why are the wires in Ethernet cables colour-coded?
The internal wires in Ethernet cables like this one are colour-coded to make it easy to arrange them according to the configuration you want to use. That could be a straight-through, crossover or rollover configuration.
Standards
ISO/IEC 11803; EN 50173
