Belden Unterminated, 305 m Cat5E Cable, Grey Polyvinyl Chloride Sheath
- RS Stock No.:
- 631-663
- Mfr. Part No.:
- 1633ES.00305
- Brand:
- Belden
Subtotal (1 reel of 305 metres)*
£443.47
(exc. VAT)
£532.16
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 1 unit(s) shipping from 11 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £443.47 | £1.454 |
*price indicative
- RS Stock No.:
- 631-663
- Mfr. Part No.:
- 1633ES.00305
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Belden | |
| Series | Unterminated | |
| Product Type | Cat5E Cable | |
| Cable Length | 305m | |
| Sub Type | Cat5e | |
| Jacket Colour | Grey | |
| Jacket Material | Polyvinyl Chloride | |
| Conductor Type | Stranded | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | 60°C | |
| Standards/Approvals | REACH, EU CE, RoHS, IEC 60332-1-2 | |
| Fire Behaviour | IEC 60332-1-2 | |
| Conductor Material | Bare Copper | |
| Number of Cores | 4 | |
| Voltage | 72V | |
| Outside Diameter | 6mm | |
| Select all | ||
|---|---|---|
Brand Belden | ||
Series Unterminated | ||
Product Type Cat5E Cable | ||
Cable Length 305m | ||
Sub Type Cat5e | ||
Jacket Colour Grey | ||
Jacket Material Polyvinyl Chloride | ||
Conductor Type Stranded | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature 60°C | ||
Standards/Approvals REACH, EU CE, RoHS, IEC 60332-1-2 | ||
Fire Behaviour IEC 60332-1-2 | ||
Conductor Material Bare Copper | ||
Number of Cores 4 | ||
Voltage 72V | ||
Outside Diameter 6mm | ||
- COO (Country of Origin):
- HU
Belden 1633ES Series Thin Ethernet Cable, 305m Cable Length, Grey Jacket - 1633ES.00305
This thin Ethernet cable is designed to provide Compact network connectivity for industrial and commercial systems where space is limited. It delivers Cat5e performance in a slim grey PVC-sheathed construction suitable for structured cabling and patching in automation, electronics and electrical installations.
Features & Benefits
• Stranded bare copper conductors enable flexible routing in confined runs
• Flame-retardant PVC jacket meets IEC60332-1-2 for improved safety
• Rated for operation between -30°C and 60°C for varied environments
• 72V nominal voltage supports low-voltage network applications
• Four-core configuration supports standard Cat5e signal pairs
• 6mm outside diameter provides a low-profile solution for tight spaces
• Flame-retardant PVC jacket meets IEC60332-1-2 for improved safety
• Rated for operation between -30°C and 60°C for varied environments
• 72V nominal voltage supports low-voltage network applications
• Four-core configuration supports standard Cat5e signal pairs
• 6mm outside diameter provides a low-profile solution for tight spaces
**Applications**
• Suitable for internal patching in control panels and cabinets
• Ideal for communication runs in automation assembly cells
• Used with Ethernet switches in factory-floor wiring ducts
• Can be used for instrument and sensor network links in machinery
• Suitable for bulk spooling for long-distance workstation feeds
• Ideal for communication runs in automation assembly cells
• Used with Ethernet switches in factory-floor wiring ducts
• Can be used for instrument and sensor network links in machinery
• Suitable for bulk spooling for long-distance workstation feeds
How is flexibility achieved for routing through cable trays?
Flexibility derives from the stranded copper conductors which reduce stiffness and ease bends during instalment in trays and conduits.
What environmental conditions can the cable tolerate during operation?
The jacket and conductor combination permits continuous use at temperatures from -30°C up to 60°C without degrading electrical function.
Which safety and material regulations does the cable comply with?
The construction conforms to chemical and environmental restrictions and carries REACH, RoHS and CE designations, with a jacket that meets IEC60332-1-2 flame performance.
How is identification and colour management handled on-site?
The cable is supplied with a grey outer jacket to aid segregation of network cabling from other services in wiring bundles.
