Finder 39 Series Interface Relay, DIN Rail Mount, 230V ac Coil, SPST

RS Stock No.:: 819-8953
Mfr. Part No.:: 39.51.8.230.0060
Brand:: Finder

Finder 39 Series Interface Relay, DIN Rail Mount, 230V ac Coil, SPST

Available to back order for despatch 24/09/2024

Added

Price Each

£24.98

(exc. VAT)

£29.98

(inc. VAT)

Units	Per unit
1 - 4	£24.98
5 - 9	£24.22
10 +	£23.19

RS Stock No.:: 819-8953
Mfr. Part No.:: 39.51.8.230.0060
Brand:: Finder

Technical Reference

Datasheet

Legislation and Compliance

COO (Country of Origin):: IT

Product Details

39 Series - EMR Screw Terminals

A range of electromechanical relay interface modules from the 39 series from Finder, these relays have a high switching capability.

Space saving 6.2 mm wide
Connections for 16-way jumper link
Integral coil indication and protection circuit
Secure retention and easy ejection by plastic clip
Dual screw head (blade+cross) terminals
35 mm DIN rail mounting

Specifications

Attribute	Value
Coil Voltage	230V ac
Contact Configuration	SPST
Mounting Type	DIN Rail
Maximum Input Voltage	264V ac/dc
Minimum Input Voltage	184V ac/dc
Terminal Type	Push In
Switching Voltage	250 → 400V ac
Depth	90.7mm
Height	87mm
Length	6.2mm
Series	39 Series
Contact Material	Silver Alloy
Input Current	4.3mA
Operating Temperature Range	-40 → +70°C
Turn On Time	5ms
Minimum Operating Temperature	-40°C
Special Features	Protection category IP 20
Maximum Operating Temperature	+70°C
Input Voltage Range	184 → 264V
Dimensions	6.2 x 90.7 x 87mm
Turn Off Time	6ms
