Finder 39 Series Interface Relay, DIN Rail Mount, 125V ac Coil, SPDT, 1-Pole
- RS Stock No.:
- 776-1493
- Mfr. Part No.:
- 39.31.0.125.0060
- Brand:
- Finder
6 In stock - FREE next working day delivery available
Added
Price Each
£9.44
(exc. VAT)
£11.33
(inc. VAT)
| Units | Per unit |
| 1 + | £9.44 |
- RS Stock No.:
- 776-1493
- Mfr. Part No.:
- 39.31.0.125.0060
- Brand:
- Finder
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- IT
Product Details
39 Series - EMR Screw Terminals
A range of electromechanical relay interface modules from the 39 series from Finder, these relays have a high switching capability.
Space saving 6.2 mm wide
Connections for 16-way jumper link
Integral coil indication and protection circuit
Secure retention and easy ejection by plastic clip
Dual screw head (blade+cross) terminals
35 mm DIN rail mounting
Connections for 16-way jumper link
Integral coil indication and protection circuit
Secure retention and easy ejection by plastic clip
Dual screw head (blade+cross) terminals
35 mm DIN rail mounting
Specifications
Attribute | Value |
|---|---|
| Coil Voltage | 125V ac |
| Contact Configuration | SPDT |
| Mounting Type | DIN Rail |
| Number of Poles | 1 |
| Terminal Type | Screw |
| Depth | 90.7mm |
| Height | 94.3mm |
| Length | 6.2mm |
| Series | 39 Series |
| Contact Material | Silver Alloy |
| Minimum Operating Temperature | -40°C |
| Life | 60 x 10³ cycles |
| Maximum Operating Temperature | +70°C |
