Legrand 8000 VA DIN Rail Transformer, 400 V, 460 V Primary, EN 60439-1, IEC EN 61558-2-6, IEC EN 61558-2-4, EN 60204-1,
- RS Stock No.:
- 620-3104
- Mfr. Part No.:
- 0 442 15
- Brand:
- Legrand
Bulk discount available
Subtotal (1 unit)*
£208.19
(exc. VAT)
£249.83
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2 unit(s) shipping from 27 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 24 | £208.19 |
| 25 + | £190.92 |
*price indicative
- RS Stock No.:
- 620-3104
- Mfr. Part No.:
- 0 442 15
- Brand:
- Legrand
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Legrand | |
| Primary Voltage | 400 V, 460 V | |
| Product Type | DIN Rail Transformer | |
| Mount Type | Clip, Direct, Plate | |
| Power | 8000VA | |
| Minimum Operating Frequency | 50Hz | |
| Termination Type | Primary Terminal | |
| Maximum Operating Frequency | 60Hz | |
| Weight | 64kg | |
| Maximum Operating Temperature | 50°C | |
| Standards/Approvals | EN 60439-1, IEC EN 61558-2-6, IEC EN 61558-2-4, EN 60204-1, EN 61131-2 | |
| Select all | ||
|---|---|---|
Brand Legrand | ||
Primary Voltage 400 V, 460 V | ||
Product Type DIN Rail Transformer | ||
Mount Type Clip, Direct, Plate | ||
Power 8000VA | ||
Minimum Operating Frequency 50Hz | ||
Termination Type Primary Terminal | ||
Maximum Operating Frequency 60Hz | ||
Weight 64kg | ||
Maximum Operating Temperature 50°C | ||
Standards/Approvals EN 60439-1, IEC EN 61558-2-6, IEC EN 61558-2-4, EN 60204-1, EN 61131-2 | ||
- COO (Country of Origin):
- FR
Control and signalling transformers, 442 series
Single-phase control and signalling transformers (50 → 60 Hz - class 1).
Active parts protected by cover up to 1000 VA.
Mounting on full or perforated platinum, or rail according to power.
Direct mounting possible on symmetrical DIN rail up to 250 VA.
More compact than previous models (423 series).
Interference filtering (except stock no. 620-3110).
Voltage adjustment: ±15 V.
Features a marking area.
Supplied with connection strip 0 V secondary earth terminal.
Approvals
CSA C22-2-N°66.
Standards
EN 61131-2, EN 60204-1 and EN60439-1, IEC EN 61558-2-2 and 2-4 or 2-6, UL506
