TDK-Lambda PXC-M03W DC-DC Converter, 5V dc/ 600mA Output, 18 → 75 V dc Input, 3W, PCB Mount, +94°C Max Temp

View this category
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
RS Stock No.:
914-7726
Mfr. Part No.:
PXC-M03-48WS05
Brand:
TDK-Lambda
Find similar products by selecting one or more attributes.
Select all

Brand

TDK-Lambda

Output Voltage

5V dc

Input Voltage Range

18 → 75 V dc

Power Rating

3W

Input Voltage Nominal

48 V dc

Output Current

600mA

Mounting Type

PCB Mount

Isolated

Yes

Number of Outputs

1

Output Voltage Adjustment Range

±10%

Isolation Voltage

5kV ac

Length

31.8mm

Depth

10.2mm

Width

20.3mm

Railway Approved

No

Series

PXC-M03W

Minimum Temperature

-40°C

Maximum Temperature

+94°C

Standards Met

60601-1 Approval, ANSI/AAMI ES60601-1, CE Mark, Class A and FCC part 18, Easier System Approval, EN55011, EN55022, EN60601-1, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, IEC60601-1, MIL-STD-810F

Medical Approved

Yes
