TRACOPOWER TEL 10 DC-DC Converter, 12V dc/ 833mA Output, 36 → 75 V dc Input, 10W, Through Hole, +85°C Max Temp
- RS Stock No.:
- 187-5116
- Mfr. Part No.:
- TEL 10-4812
- Brand:
- TRACOPOWER
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 187-5116
- Mfr. Part No.:
- TEL 10-4812
- Brand:
- TRACOPOWER
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TRACOPOWER | |
Output Voltage | 12V dc | |
Input Voltage Range | 36 → 75 V dc | |
Power Rating | 10W | |
Input Voltage Nominal | 48 V dc | |
Output Current | 833mA | |
Mounting Type | Through Hole | |
Isolated | Yes | |
Number of Outputs | 1 | |
Package | DIP | |
Isolation Voltage | 1kV dc | |
Length | 23.8mm | |
Width | 13.7mm | |
Depth | 8mm | |
Series | TEL 10 | |
Load Regulation | 0.01 | |
Maximum Temperature | +85°C | |
Minimum Temperature | -40°C | |
Efficiency | 87% | |
Select all | ||
---|---|---|
Brand TRACOPOWER | ||
Output Voltage 12V dc | ||
Input Voltage Range 36 → 75 V dc | ||
Power Rating 10W | ||
Input Voltage Nominal 48 V dc | ||
Output Current 833mA | ||
Mounting Type Through Hole | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Package DIP | ||
Isolation Voltage 1kV dc | ||
Length 23.8mm | ||
Width 13.7mm | ||
Depth 8mm | ||
Series TEL 10 | ||
Load Regulation 0.01 | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
Efficiency 87% | ||
