TRACOPOWER TEL 10 DC/DC Converter, 12V dc/ 833 mA, 36V dc Input, 18V Input 10 W, PCB, 85 °C Max Temp -40 °C Min Temp

View all DC-DC Converters
Bulk discount available

Subtotal (1 unit)*

£23.09

(exc. VAT)

£27.71

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • Plus 14 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
1 - 4£23.09
5 - 9£22.39
10 - 24£21.70
25 - 49£20.78
50 +£19.85

*price indicative

Better World

Our Better World range features products that make it easy for you to make a greener product choice you can trust. Click here to find out more.

RS Stock No.:
187-5083
Distrelec Article No.:
301-48-833
Mfr. Part No.:
TEL 10-2412
Brand:
TRACOPOWER
Find similar products by selecting one or more attributes.
Select all

Brand

TRACOPOWER

Product Type

DC/DC Converter

Output Voltage 1

12V dc

Minimum Input Voltage

18V

Maximum Input Voltage

36V dc

Output Current 1

833mA

Mount Type

PCB

Input Ratio

2:1

Number of Outputs

1

MTBF

1000000h

Isolation Voltage

1kV dc

Maximum Output Power

10W

Package Type

DIP-16

Length

23.8mm

Standards/Approvals

No

Series

TEL 10

Depth

8mm

Width

13.7mm

Better World Product

Yes

Better World Claim

Concentrated or Compact Solution

Maximum Operating Temperature

85°C

Efficiency

87%

Minimum Operating Temperature

-40°C

TRACOPOWER TEL 10 Series DC-DC Converter, 18 to 36V DC Input Voltage Range, 10W Power Rating - TEL 10-2412


The TEL 10 series DC-DC converter offers a compact and efficient solution for low-power applications. It has dimensions of 23.8mm in length, 13.7mm in width, and a height of just 8mm. Operating within an input voltage range of 18 to 36 V DC, it delivers a stable output voltage of 12V DC, with an output current of 833 mA and a power rating of 10W, ensuring consistent performance across various applications.

Features & Benefits


• Compact DIP 16 package for efficient space use

• Isolated design enhances operational safety

• High efficiency of 87% minimises energy waste

• Robust temperature range suitable for harsh environments

• Integrated input filter complies with emission standards

Applications


• Ideal for instrumentation projects where space is limited

• Utilised in IT equipment requiring efficient power conversion

• Functions as a power supply in automation systems

• Compatible with various electronic device circuits

Can it operate in extreme temperatures?


Yes, it functions between -40°C and +85°C.

Will it maintain output voltage under varying loads?


Yes, it has excellent load regulation of 0.01.

Is it suitable for sensitive electronic applications?


It complies with IEC/EN 62368-1 standards for safety.
