TDK-Lambda PXC-M06W DC-DC Converter, ±15V dc/ ±200mA Output, 18 → 75 V dc Input, 6W, PCB Mount, +88°C Max Temp

RS Stock No.:: 173-9156
Mfr. Part No.:: PXC-M06-48WD15
Brand:: TDK-Lambda

TDK-Lambda PXC-M06W DC-DC Converter, ±15V dc/ ±200mA Output, 18 → 75 V dc Input, 6W, PCB Mount, +88°C Max Temp

Bulk discount available

Price 1 Tube of 10**

£444.15

(exc. VAT)

£532.98

(inc. VAT)

Available to back order for despatch 04/04/2025*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over £50.00

Tube(s)	Per Tube	Per unit**
1 - 4	£444.15	£44.415
5 - 9	£430.83	£43.083
10 - 24	£417.50	£41.75
25 - 49	£404.18	£40.418
50 +	£390.85	£39.085

**price indicative

RS Stock No.:: 173-9156
Mfr. Part No.:: PXC-M06-48WD15
Brand:: TDK-Lambda

TDK-Lambda PXC-M Series Product Preview

Attribute	Value
Output Voltage	±15V dc
Input Voltage Range	18 → 75 V dc
Power Rating	6W
Input Voltage Nominal	48 V dc
Output Current	±200mA
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	2
Output Voltage Adjustment Range	±13.5 V dc, ±16.5V dc
Isolation Voltage	5kV ac
Length	31.8mm
Width	20.3mm
Depth	10.2mm
Series	PXC-M06W
Railway Approved	No
Minimum Temperature	-40°C
Maximum Temperature	+88°C
Efficiency	87%
Medical Approved	Yes
Standards Met	60601-1 Approval, ANSI/AAMI ES60601-1, CE Mark, Class A and FCC part 18, Easier System Approval, EN55011, EN55022, EN60601-1, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, IEC60601-1, MIL-STD-810F

TDK-Lambda PXC-M06W DC-DC Converter, ±15V dc/ ±200mA Output, 18 → 75 V dc Input, 6W, PCB Mount, +88°C Max Temp

FREE delivery for orders over £50.00

TDK-Lambda Isolated DC-DC Converter, PXC-M06 Series
