Cosel MGF DC/DC Converter, 5V dc/ 600 mA, 24V dc Input, 9V Input 3 W, PCB, 85 °C Max Temp -40 °C Min Temp, 4-Pin SIP-6
- RS Stock No.:
- 171-4805
- Mfr. Part No.:
- MGFS32405
- Brand:
- Cosel
Subtotal (1 tube of 10 units)*
£113.96
(exc. VAT)
£136.75
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £113.96 | £11.396 |
*price indicative
- RS Stock No.:
- 171-4805
- Mfr. Part No.:
- MGFS32405
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 5V dc | |
| Maximum Input Voltage | 24V dc | |
| Minimum Input Voltage | 9V | |
| Output Current 1 | 600mA | |
| Output Current 2 | 0.6A | |
| Mount Type | PCB | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | 4.90 to 5.21 V | |
| Ripple and Noise | 200mV Pk-Pk | |
| Number of Pins | 4 | |
| Isolation Voltage | 1kV dc | |
| Maximum Output Power | 3W | |
| Package Type | SIP-6 | |
| Depth | 12mm | |
| Standards/Approvals | CE, C-UL, CSA, UL62368-1, RoHS, UKCA, EN62368-1, UL60950-1, EN 62368-1, cUL | |
| Weight | 4g | |
| Length | 17mm | |
| Series | MGF | |
| Width | 8.5mm | |
| Maximum Operating Temperature | 85°C | |
| Efficiency | 81% | |
| Minimum Operating Temperature | -40°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 5V dc | ||
Maximum Input Voltage 24V dc | ||
Minimum Input Voltage 9V | ||
Output Current 1 600mA | ||
Output Current 2 0.6A | ||
Mount Type PCB | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range 4.90 to 5.21 V | ||
Ripple and Noise 200mV Pk-Pk | ||
Number of Pins 4 | ||
Isolation Voltage 1kV dc | ||
Maximum Output Power 3W | ||
Package Type SIP-6 | ||
Depth 12mm | ||
Standards/Approvals CE, C-UL, CSA, UL62368-1, RoHS, UKCA, EN62368-1, UL60950-1, EN 62368-1, cUL | ||
Weight 4g | ||
Length 17mm | ||
Series MGF | ||
Width 8.5mm | ||
Maximum Operating Temperature 85°C | ||
Efficiency 81% | ||
Minimum Operating Temperature -40°C | ||
- COO (Country of Origin):
- JP
The Cosel robust DC-DC converter designed for PCB mounting, offering a 10:1 input range for exceptional versatility in power management.
Wide input range of DC18 to 36V allows flexibility in power supply
High efficiency of 80% typical enhances system performance
Low output ripple noise ensures stable operation
Built-in overcurrent protection adds a layer of safety
