Cosel MGF DC/DC Converter, 5V dc/ 600 mA, 48V dc Input, 18V Input 3 W, PCB, 85 °C Max Temp -40 °C Min Temp, 4-Pin SIP-6
- RS Stock No.:
- 171-4809
- Mfr. Part No.:
- MGFS34805
- Brand:
- Cosel
Subtotal (1 tube of 10 units)*
£66.50
(exc. VAT)
£79.80
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 07 December 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £66.50 | £6.65 |
*price indicative
- RS Stock No.:
- 171-4809
- Mfr. Part No.:
- MGFS34805
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Product Type | DC/DC Converter | |
| Output Voltage 1 | 5V dc | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 48V dc | |
| Output Current 1 | 600mA | |
| Output Current 2 | 2A | |
| Mount Type | PCB | |
| Output Voltage 2 | 12V | |
| Number of Outputs | 1 | |
| Ripple and Noise | 200mV Pk-Pk | |
| Output Voltage Adjustment Range | 4.90 → 5.21 V | |
| Isolation Voltage | 1kV dc | |
| Number of Pins | 4 | |
| Maximum Output Power | 3W | |
| Package Type | SIP-6 | |
| Series | MGF | |
| Width | 8.5mm | |
| Standards/Approvals | RoHS, CE, EN62368-1, UKCA, CSA, EN 62368-1, UL62368-1, cUL, C-UL, UL60950-1 | |
| Weight | 4g | |
| Length | 17mm | |
| Depth | 12mm | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 80% | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand Cosel | ||
Product Type DC/DC Converter | ||
Output Voltage 1 5V dc | ||
Minimum Input Voltage 18V | ||
Maximum Input Voltage 48V dc | ||
Output Current 1 600mA | ||
Output Current 2 2A | ||
Mount Type PCB | ||
Output Voltage 2 12V | ||
Number of Outputs 1 | ||
Ripple and Noise 200mV Pk-Pk | ||
Output Voltage Adjustment Range 4.90 → 5.21 V | ||
Isolation Voltage 1kV dc | ||
Number of Pins 4 | ||
Maximum Output Power 3W | ||
Package Type SIP-6 | ||
Series MGF | ||
Width 8.5mm | ||
Standards/Approvals RoHS, CE, EN62368-1, UKCA, CSA, EN 62368-1, UL62368-1, cUL, C-UL, UL60950-1 | ||
Weight 4g | ||
Length 17mm | ||
Depth 12mm | ||
Minimum Operating Temperature -40°C | ||
Efficiency 80% | ||
Maximum Operating Temperature 85°C | ||
- COO (Country of Origin):
- JP
The Cosel DC-DC Converter offers high-efficiency performance in a Compact design, designed for PCB mounting. It facilitates reliable power conversion across various input voltages and is engineered for enhanced electrical safety.
High efficiency achieved by synchronous rectification for reduced energy loss
Features built-in overcurrent and overvoltage protection for enhanced safety
Provides a wide input voltage range of DC18 to 36V
Compact size facilitates easy integration into space-constrained applications
