Cosel CHS DC-DC Converter, 5V dc/ 40A Output, 18 → 36 V dc Input, 200W, PCB Mount, +85°C Max Temp -40°C Min Temp
- RS Stock No.:
- 132-5406
- Mfr. Part No.:
- CHS3002405
- Brand:
- Cosel
Bulk discount available
Subtotal (1 unit)*
£78.63
(exc. VAT)
£94.36
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 12 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £78.63 |
| 5 - 9 | £76.26 |
| 10 - 24 | £74.70 |
| 25 - 49 | £73.12 |
| 50 + | £71.55 |
*price indicative
- RS Stock No.:
- 132-5406
- Mfr. Part No.:
- CHS3002405
- Brand:
- Cosel
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage | 5V dc | |
| Input Voltage Range | 18 → 36 V dc | |
| Power Rating | 200W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 40A | |
| Mounting Type | PCB Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | ±20% | |
| Package | DIP | |
| Isolation Voltage | 1 kV ac, 500V dc | |
| Depth | 11mm | |
| Width | 22.86mm | |
| Length | 58.4mm | |
| Series | CHS | |
| Load Regulation | 10mV | |
| Standards Met | CE, cUL (CSA 60950-1), cULus Recognised, EN 60950-1, UL 60950-1 | |
| Maximum Temperature | +85°C | |
| Minimum Temperature | -40°C | |
| Efficiency | 93.5% | |
Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage 5V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 200W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 40A | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range ±20% | ||
Package DIP | ||
Isolation Voltage 1 kV ac, 500V dc | ||
Depth 11mm | ||
Width 22.86mm | ||
Length 58.4mm | ||
Series CHS | ||
Load Regulation 10mV | ||
Standards Met CE, cUL (CSA 60950-1), cULus Recognised, EN 60950-1, UL 60950-1 | ||
Maximum Temperature +85°C | ||
Minimum Temperature -40°C | ||
Efficiency 93.5% | ||
