Cosel CHS DC-DC Converter, 15V dc/ 13.5A Output, 18 → 36 V dc Input, 202.5W, PCB Mount, +85°C Max Temp -40°C Min
- RS Stock No.:
- 132-5408
- Mfr. Part No.:
- CHS3002415
- Brand:
- Cosel
Bulk discount available
Subtotal (1 unit)*
£85.93
(exc. VAT)
£103.12
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £85.93 |
| 5 - 9 | £83.35 |
| 10 - 24 | £81.63 |
| 25 - 49 | £79.92 |
| 50 + | £78.20 |
*price indicative
- RS Stock No.:
- 132-5408
- Mfr. Part No.:
- CHS3002415
- Brand:
- Cosel
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Cosel | |
| Output Voltage | 15V dc | |
| Input Voltage Range | 18 → 36 V dc | |
| Power Rating | 202.5W | |
| Input Voltage Nominal | 24 V dc | |
| Output Current | 13.5A | |
| Mounting Type | PCB Mount | |
| Isolated | Yes | |
| Number of Outputs | 1 | |
| Output Voltage Adjustment Range | -20/+5% | |
| Package | DIP | |
| Isolation Voltage | 1 kV ac, 500V dc | |
| Width | 22.86mm | |
| Depth | 11mm | |
| Length | 58.4mm | |
| Series | CHS | |
| Load Regulation | 30mV | |
| Maximum Temperature | +85°C | |
| Efficiency | 93.5% | |
| Minimum Temperature | -40°C | |
| Standards Met | CE, cUL (CSA 60950-1), cULus Recognised, EN 60950-1, UL 60950-1 | |
Select all | ||
|---|---|---|
Brand Cosel | ||
Output Voltage 15V dc | ||
Input Voltage Range 18 → 36 V dc | ||
Power Rating 202.5W | ||
Input Voltage Nominal 24 V dc | ||
Output Current 13.5A | ||
Mounting Type PCB Mount | ||
Isolated Yes | ||
Number of Outputs 1 | ||
Output Voltage Adjustment Range -20/+5% | ||
Package DIP | ||
Isolation Voltage 1 kV ac, 500V dc | ||
Width 22.86mm | ||
Depth 11mm | ||
Length 58.4mm | ||
Series CHS | ||
Load Regulation 30mV | ||
Maximum Temperature +85°C | ||
Efficiency 93.5% | ||
Minimum Temperature -40°C | ||
Standards Met CE, cUL (CSA 60950-1), cULus Recognised, EN 60950-1, UL 60950-1 | ||
- COO (Country of Origin):
- JP
CHS Series
The CHS Series of DC-DC converters offer a wide range of power ratings and output voltages making them extremely versatile and suitable for many applications. Additional features include remote sensing, remote on/off, overcurrent and overvoltage protection.
5 Year Warranty
5 Year Warranty
Features and Benefits
• Standard-size compact DC-DC Converter, "BRICK SIZE" for the Telecommunications Market
• High efficiency
• High density
• High reliability: no built-in aluminium and tantalum electrolytic capacitor
• Built-in remote On/Off
• High efficiency
• High density
• High reliability: no built-in aluminium and tantalum electrolytic capacitor
• Built-in remote On/Off
