MEAN WELL MDS20 DC/DC Converter, 12V dc/ 1.67 A, 36V dc Input, 18V dc Input 20 W, 90 °C Max Temp -40 °C Min Temp, 5-Pin

View all DC-DC Converters

Subtotal (1 unit)*

£31.36

(exc. VAT)

£37.63

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • 2 unit(s) shipping from 04 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£31.36

*price indicative

RS Stock No.:
424-978
Distrelec Article No.:
302-29-978
Mfr. Part No.:
MDS20B-12
Brand:
MEAN WELL
Find similar products by selecting one or more attributes.
Select all

Brand

MEAN WELL

Product Type

DC/DC Converter

Output Voltage 1

12V dc

Minimum Input Voltage

18V dc

Maximum Input Voltage

36V dc

Output Current 1

1.67A

Output Current 2

1.67A

Output Voltage 2

12V dc

MTBF

1016kH

Ripple and Noise

60mV Pk-Pk

Number of Pins

5

Maximum Output Power

20W

Series

MDS20

Width

25.4mm

Standards/Approvals

RoHS, ENEN55011

Length

50.8mm

Efficiency

0.88%

Maximum Operating Temperature

90°C

Minimum Operating Temperature

-40°C

RoHS Status: Exempt

COO (Country of Origin):
TW
The MEANWELL DC-DC medical Converter PCB mount features a wide input range of 18 to 36Vdc. It provides a single output of 12Vdc at 1.67A. The converter is in a DIP through-hole package and offers 2xMOPP (Means of Patient Protection) certification.

Warranty pack 36 Months Bring-In

RoHS Compliant

Packing quantity 432
