MEAN WELL RSD DC/DC Converter, 12V dc/ 1.67 A, 75V dc Input, 75V dc Input 20 W, PCB, 85 °C Max Temp -40 °C Min Temp,
- RS Stock No.:
- 149-671
- Distrelec Article No.:
- 302-30-066
- Mfr. Part No.:
- RSDW20G-12
- Brand:
- MEAN WELL
Subtotal (1 unit)*
£27.48
(exc. VAT)
£32.98
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 1 unit(s) ready to ship
- Plus 1 unit(s) shipping from 31 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £27.48 |
*price indicative
- RS Stock No.:
- 149-671
- Distrelec Article No.:
- 302-30-066
- Mfr. Part No.:
- RSDW20G-12
- Brand:
- MEAN WELL
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | MEAN WELL | |
| Output Voltage 1 | 12V dc | |
| Product Type | DC/DC Converter | |
| Maximum Input Voltage | 75V dc | |
| Minimum Input Voltage | 75V dc | |
| Output Current 1 | 1.67A | |
| Output Current 2 | 2000mA | |
| Output Voltage 2 | 15V | |
| Mount Type | PCB | |
| MTBF | 880kH | |
| Number of Outputs | 2 | |
| Output Voltage Adjustment Range | ±10 % | |
| Ripple and Noise | 60mV Pk-Pk | |
| Number of Pins | 6 | |
| Isolation Voltage | 3kV | |
| Maximum Output Power | 20W | |
| Package Type | 2 x 1 in | |
| Series | RSD | |
| Width | 25.4mm | |
| Standards/Approvals | IEC60571, EN61373, EN50155, EN50121-3-2, EAC TP TC 020/2011, BS EN/EN55032 | |
| Weight | 35g | |
| Length | 50.8mm | |
| Depth | 10.2mm | |
| Minimum Operating Temperature | -40°C | |
| Efficiency | 90% | |
| Maximum Operating Temperature | 85°C | |
| Select all | ||
|---|---|---|
Brand MEAN WELL | ||
Output Voltage 1 12V dc | ||
Product Type DC/DC Converter | ||
Maximum Input Voltage 75V dc | ||
Minimum Input Voltage 75V dc | ||
Output Current 1 1.67A | ||
Output Current 2 2000mA | ||
Output Voltage 2 15V | ||
Mount Type PCB | ||
MTBF 880kH | ||
Number of Outputs 2 | ||
Output Voltage Adjustment Range ±10 % | ||
Ripple and Noise 60mV Pk-Pk | ||
Number of Pins 6 | ||
Isolation Voltage 3kV | ||
Maximum Output Power 20W | ||
Package Type 2 x 1 in | ||
Series RSD | ||
Width 25.4mm | ||
Standards/Approvals IEC60571, EN61373, EN50155, EN50121-3-2, EAC TP TC 020/2011, BS EN/EN55032 | ||
Weight 35g | ||
Length 50.8mm | ||
Depth 10.2mm | ||
Minimum Operating Temperature -40°C | ||
Efficiency 90% | ||
Maximum Operating Temperature 85°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
The MEANWELL DC-DC Railway Single Output Converter is designed to operate efficiently in transportation applications. With an input range of 18-75VDC, it provides a reliable 12VDC output at 1.67A. Featuring 1.5KVDC isolation and a remote ON/OFF function, this converter ensures stable power delivery for your railway systems.
Input Voltage Range 18-75VDC
Output Voltage 12VDC at 1.67A
1.5KVDC I/O Isolation for Safety
DIP Through Hole Package for Easy Installation
Remote ON/OFF Functionality for Control
Warranty 36 Months Bring-In
Compact Design for Space Efficiency
