MEAN WELL RSD DC/DC Converter, 12V dc/ 1.67 A, 36V dc Input, 36V dc Input 20 W, PCB, 85 °C Max Temp -40 °C Min Temp,

View all DC-DC Converters

Subtotal (1 unit)*

£27.48

(exc. VAT)

£32.98

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 19 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£27.48

*price indicative

RS Stock No.:
149-676
Distrelec Article No.:
302-30-062
Mfr. Part No.:
RSDW20F-12
Brand:
MEAN WELL
Find similar products by selecting one or more attributes.
Select all

Brand

MEAN WELL

Output Voltage 1

12V dc

Product Type

DC/DC Converter

Minimum Input Voltage

36V dc

Maximum Input Voltage

36V dc

Output Current 1

1.67A

Output Current 2

2000mA

Output Voltage 2

15V

Mount Type

PCB

Number of Outputs

2

MTBF

880kH

Ripple and Noise

60mV Pk-Pk

Output Voltage Adjustment Range

±10 %

Isolation Voltage

3kV

Number of Pins

6

Maximum Output Power

20W

Package Type

2 x 1 in

Standards/Approvals

EAC TP TC 004, EAC TP TC 020/2011, EN50121-3-2, EN50155, EN61373, IEC60571, BS EN/EN55032

Weight

35g

Length

50.8mm

Width

25.4mm

Series

RSD

Efficiency

90%

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

85°C

RoHS Status: Exempt

COO (Country of Origin):
CN
The MEANWELL DC-DC Railway Single Output Converter with an input range of 9-36VDC and an output of 12VDC at 1.67A. It offers 1.5KVDC I/O isolation and comes in a DIP Through hole package. With remote ON/OFF functionality, this converter is versatile and reliable for various applications in the railway industry.

Input range of 9-36VDC for flexible use

Output of 12VDC at 1.67A for efficient power supply

1.5KVDC I/O isolation for safety and protection

DIP Through hole package for easy installation

Remote ON/OFF feature for convenient operation
