ASSMANN WSW A-DF 25 Way Right Angle 2.77 mm Pitch Panel Mount D-Sub Connector
- RS Stock No.:
- 674-1025
- Mfr. Part No.:
- A-DF 25 LL-WP
- Brand:
- ASSMANN WSW
Subtotal (1 unit)*
£16.55
(exc. VAT)
£19.86
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 03 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £16.55 |
*price indicative
- RS Stock No.:
- 674-1025
- Mfr. Part No.:
- A-DF 25 LL-WP
- Brand:
- ASSMANN WSW
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | ASSMANN WSW | |
| Product Type | D-Sub Connector | |
| Number of Contacts | 25 | |
| Orientation | Right Angle | |
| Current | 5A | |
| Mount Type | Panel Mount | |
| Connector Type D | D-Sub | |
| D-Sub Shell Size | B | |
| Housing Material | Metal | |
| Voltage | 250.0 V | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | No | |
| Series | A-DF | |
| Contact Material | Brass | |
| Contact Plating | Nickel, Gold | |
| Pitch | 2.77mm | |
| Select all | ||
|---|---|---|
Brand ASSMANN WSW | ||
Product Type D-Sub Connector | ||
Number of Contacts 25 | ||
Orientation Right Angle | ||
Current 5A | ||
Mount Type Panel Mount | ||
Connector Type D D-Sub | ||
D-Sub Shell Size B | ||
Housing Material Metal | ||
Voltage 250.0 V | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Contact Gender Female | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals No | ||
Series A-DF | ||
Contact Material Brass | ||
Contact Plating Nickel, Gold | ||
Pitch 2.77mm | ||
- COO (Country of Origin):
- TW
D-Sub with Solder Cup, IP67
Panel mount solder bucket D-sub connectors rated to IP67.
Assmann
