Harting D-Sub 9 Way Right Angle Through Hole D-sub Connector Socket, 2.77mm Pitch, with 4-40 UNC Screwlocks

RS Stock No.:: 139-3692
Mfr. Part No.:: 09681535613
Brand:: HARTING

Harting D-Sub 9 Way Right Angle Through Hole D-sub Connector Socket, 2.77mm Pitch, with 4-40 UNC Screwlocks

85 In stock - FREE next working day delivery available

Price Each (In a Pack of 50)

£3.602

(exc. VAT)

£4.322

(inc. VAT)

Units	Per unit	Per Pack*
50 - 50	£3.602	£180.10
100 - 200	£3.061	£153.05
250 - 450	£2.701	£135.05
500 +	£2.424	£121.20

*price indicative

RS Stock No.:: 139-3692
Mfr. Part No.:: 09681535613
Brand:: HARTING

Technical Reference

Female 9 way D-sub connector drawing

Legislation and Compliance

COO (Country of Origin):: CN

Product Details

Harting 9, 15 and 25 way Solder D-Sub Miniature Sockets - U.S Footprint

From Harting, a range of solder D-Sub miniature connectors with stamped and angled female contacts. The U.S footprint sockets have copper alloy contacts in a robust metal shell with extra grounding pin. Secured in the panel with a fixing flange and 4 - 40 UNC screw lock. The D-Sub miniature connectors in this range have a performance level S2.

Features and Benefits

• Robust metal shell
• 6.5A rated current
• Wave solder termination
• Extra grounding pin
• U.S footprint
• Stamped angled contacts

D-Sub Connectors - Harting

Specifications

Attribute	Value
Number of Contacts	9
Gender	Female
Body Orientation	Right Angle
Mounting Type	Through Hole
Pitch	2.77 mm, 2.84mm
D Connector Type	Standard D-Sub
Mounting Hardware	4-40 UNC Screwlocks
Termination Method	Solder
Mixed Contact Layout	9W2
Current Rating	6.5A
Housing Material	Glass Fibre Reinforced Thermoplastic
Length	30.9mm
Width	12.55mm
Depth	18.2mm
Dimensions	30.9 x 12.55 x 18.2mm
Contact Material	Copper Alloy
Series	D-Sub
Maximum Operating Temperature	+125°C
Minimum Operating Temperature	-55.0°C
