HARTING D-Sub 9 Way Through Hole D-sub Connector Socket, 2.74mm Pitch, with 4-40 UNC Screwlocks
- RS Stock No.:
- 141-0349
- Mfr. Part No.:
- 09661517513
- Brand:
- HARTING
Bulk discount available
Subtotal (1 unit)*
£5.46
(exc. VAT)
£6.55
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 42 unit(s) shipping from 27 October 2025
- Plus 48 unit(s) shipping from 03 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £5.46 |
| 10 - 24 | £5.27 |
| 25 - 49 | £4.59 |
| 50 + | £4.37 |
*price indicative
- RS Stock No.:
- 141-0349
- Mfr. Part No.:
- 09661517513
- Brand:
- HARTING
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARTING | |
| Number of Contacts | 9 | |
| Gender | Female | |
| Body Orientation | Straight | |
| Mounting Type | Through Hole | |
| Pitch | 2.74 mm, 2.84mm | |
| D Connector Type | Standard D-Sub | |
| Termination Method | Solder | |
| Mounting Hardware | 4-40 UNC Screwlocks | |
| Mixed Contact Layout | 9W2 | |
| Current Rating | 6.5A | |
| Housing Material | Glass Fibre Reinforced Thermoplastic | |
| Length | 31.2mm | |
| Width | 12.5mm | |
| Depth | 12.4mm | |
| Contact Material | Copper Alloy | |
| Series | D-Sub | |
| Dimensions | 31.2 x 12.5 x 12.4mm | |
| Maximum Operating Temperature | +125°C | |
| Minimum Operating Temperature | -55.0°C | |
Select all | ||
|---|---|---|
Brand HARTING | ||
Number of Contacts 9 | ||
Gender Female | ||
Body Orientation Straight | ||
Mounting Type Through Hole | ||
Pitch 2.74 mm, 2.84mm | ||
D Connector Type Standard D-Sub | ||
Termination Method Solder | ||
Mounting Hardware 4-40 UNC Screwlocks | ||
Mixed Contact Layout 9W2 | ||
Current Rating 6.5A | ||
Housing Material Glass Fibre Reinforced Thermoplastic | ||
Length 31.2mm | ||
Width 12.5mm | ||
Depth 12.4mm | ||
Contact Material Copper Alloy | ||
Series D-Sub | ||
Dimensions 31.2 x 12.5 x 12.4mm | ||
Maximum Operating Temperature +125°C | ||
Minimum Operating Temperature -55.0°C | ||
- COO (Country of Origin):
- RO
Harting 9 way Solder D-Sub Miniature Sockets Straight - 2.74 mm Pitch
From Harting, a range of 9 way solder D-sub miniature connectors with straight stamped female contacts. The DIN 41652 sockets have copper alloy contacts housed in a robust metal shell. Secured in the panel with a fixing flange and 4 to 40 UNC thread. The D-sub miniature connectors in this series have performance level 2 and 3.
Features and Benefits
• Robust metal shell
• 6.5A rated current
• Wave soldering termination
• Performance level 2 and 3
• Stamped contacts
• 6.5A rated current
• Wave soldering termination
• Performance level 2 and 3
• Stamped contacts
