Abracon 12MHz Crystal ±50ppm SMD 4-Pin 3.3 x 2.5 x 1.1mm
- RS Stock No.:
- 226-0510
- Mfr. Part No.:
- FC3BQBBMM12.0-T3
- Brand:
- Abracon
Subtotal (1 reel of 3000 units)*
£474.00
(exc. VAT)
£570.00
(inc. VAT)
Stock information currently inaccessible
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 + | £0.158 | £474.00 |
*price indicative
- RS Stock No.:
- 226-0510
- Mfr. Part No.:
- FC3BQBBMM12.0-T3
- Brand:
- Abracon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Abracon | |
| Standard Frequency | 12MHz | |
| Mounting Type | Surface Mount | |
| Load Capacitance | 20pF | |
| Package Type | SMD | |
| Pin Count | 4 | |
| Dimensions | 3.3 x 2.5 x 1.1mm | |
| Frequency Tolerance | ±50ppm | |
Select all | ||
|---|---|---|
Brand Abracon | ||
Standard Frequency 12MHz | ||
Mounting Type Surface Mount | ||
Load Capacitance 20pF | ||
Package Type SMD | ||
Pin Count 4 | ||
Dimensions 3.3 x 2.5 x 1.1mm | ||
Frequency Tolerance ±50ppm | ||
The Abracon FC3BQ series is the SMD crystal with resin seal and it have termination finish of the ag. The shunt capacitance of this SMD crystal is the 3 pF and its load capacitance is the 20 pF.
Tolerances down to ±20 ppm
Stabilities down to ±10 ppm
Operating temperature range to -40°C to +85°C
Stabilities down to ±10 ppm
Operating temperature range to -40°C to +85°C
