Lapp ÖLFLEX CLASSIC 110 SY Control Cable, 7 Cores, 1 mm², SY, Screened, 50m, Transparent PVC Sheath, 18 AWG

RS Stock No.:: 454-8809
Mfr. Part No.:: 1125207
Brand:: Lapp

Lapp ÖLFLEX CLASSIC 110 SY Control Cable, 7 Cores, 1 mm², SY, Screened, 50m, Transparent PVC Sheath, 18 AWG

Subtotal (1 reel of 50 metres)*

£219.43

(exc. VAT)

£263.32

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

6 unit(s) ready to ship
Plus 3 unit(s) shipping from 12 December 2025

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Reel(s)	Per Reel	Per Metre*
1 +	£219.43	£4.389

*price indicative

RS Stock No.:: 454-8809
Mfr. Part No.:: 1125207
Brand:: Lapp

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Lapp
	Series	ÖLFLEX CLASSIC 110 SY
	Number of Cores	7
	Cross Sectional Area	1 mm²
	American Wire Gauge	18 AWG
	Conductor Material	Copper
	Sheath Material	PVC
	Sheath Colour	Transparent
	Control Cable Type	SY
	Screened/Unscreened	Screened
	Screen Type	Galvanised Steel Braid
	Length	50m
	Outer Diameter	11mm
	Minimum Bend Radius	Fixed - 6 x D Occasional Flexing - 20 x D
	Voltage Rating	300/500 V
	Current Rating	15 A
	Standards Met	IEC
	CPR Certification	Eca
	Maximum Operating Temperature	+80°C
	Fire Behaviour	Flame Retardant
	Cable Shape	Twisted Pair
	Filler Material	Non-Wicking Filler
	Conductor Resistance	19.5 Ω/km
	Bedding Material	PVC
	Minimum Operating Temperature	-40°C
	Oil Resistant	Yes
	Core Strands	32/0.2 mm
	Insulation Material	PVC
	Earth Cable	Yes

	Select all
	Brand Lapp
	Series ÖLFLEX CLASSIC 110 SY
	Number of Cores 7
	Cross Sectional Area 1 mm²
	American Wire Gauge 18 AWG
	Conductor Material Copper
	Sheath Material PVC
	Sheath Colour Transparent
	Control Cable Type SY
	Screened/Unscreened Screened
	Screen Type Galvanised Steel Braid
	Length 50m
	Outer Diameter 11mm
	Minimum Bend Radius Fixed - 6 x D Occasional Flexing - 20 x D
	Voltage Rating 300/500 V
	Current Rating 15 A
	Standards Met IEC
	CPR Certification Eca
	Maximum Operating Temperature +80°C
	Fire Behaviour Flame Retardant
	Cable Shape Twisted Pair
	Filler Material Non-Wicking Filler
	Conductor Resistance 19.5 Ω/km
	Bedding Material PVC
	Minimum Operating Temperature -40°C
	Oil Resistant Yes
	Core Strands 32/0.2 mm
	Insulation Material PVC
	Earth Cable Yes

COO (Country of Origin):: DE

LAPP ÖLFLEX CLASSIC 110 SY Series Control Cable, Galvanised Steel Braid, Copper Conductor - 1125207

This PVC-insulated control cable by LAPP features a 1mm² copper conductor is a versatile solution for various industrial applications. With ECA certification, galvanised steel braid, and 7 cores, this cable ensures reliability and high performance in demanding environments.

Features & Benefits

• PVC insulation and galvanised steel braid provide excellent mechanical protection
• Copper conductor with 1mm² cross-sectional area ensures optimal conductivity
• Rated at 300/500V, suitable for a wide range of industrial voltage applications
• ECA certification guarantees compliance with European fire safety standards

Applications

• Used for machine tool industry applications requiring extra mechanical protection
• Ideal for industrial automation systems and electrical equipment
• Suitable for fixed installations where flexibility and durability are paramount

Can it handle high operating temperatures?

This Lapp control cable is designed to withstand temperatures ranging from -40°C to +80°C, ensuring reliable performance in extreme conditions.

Will it provide adequate protection in industrial environments?

Yes, with a galvanised steel braid and PVC sheath, this cable offers robust protection against mechanical stress and environmental factors.

Is it suitable for complex electrical installations?

Yes, the SY type control cable with 7 cores and copper conductor is ideal for demanding electrical systems in various industries.
