Alpha Wire Alpha Essentials Communication & Control Control Cable, 3 Cores, 2.09 mm², Unscreened, 30m, Grey PVC Sheath,
- RS Stock No.:
- 187-1929
- Mfr. Part No.:
- 1891/3C SL005
- Brand:
- Alpha Wire
Subtotal (1 reel of 30 metres)*
£214.29
(exc. VAT)
£257.16
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 120 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
30 + | £7.143 | £214.29 |
*price indicative
- RS Stock No.:
- 187-1929
- Mfr. Part No.:
- 1891/3C SL005
- Brand:
- Alpha Wire
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Alpha Wire | |
Series | Alpha Essentials Communication & Control | |
Number of Cores | 3 | |
Cross Sectional Area | 2.09 mm² | |
American Wire Gauge | 14 AWG | |
Conductor Material | Tinned Copper | |
Sheath Material | PVC | |
Sheath Colour | Grey | |
Screened/Unscreened | Unscreened | |
Outer Diameter | 7.42mm | |
Minimum Bend Radius | 10 x Cable Diameter | |
Length | 30m | |
Voltage Rating | 300 V | |
Maximum Operating Temperature | +80°C | |
Core Strands | 41/30 AWG | |
Conductor Resistance | 2.8 Ω | |
Insulation Material | PVC | |
Minimum Operating Temperature | -20°C | |
Select all | ||
---|---|---|
Brand Alpha Wire | ||
Series Alpha Essentials Communication & Control | ||
Number of Cores 3 | ||
Cross Sectional Area 2.09 mm² | ||
American Wire Gauge 14 AWG | ||
Conductor Material Tinned Copper | ||
Sheath Material PVC | ||
Sheath Colour Grey | ||
Screened/Unscreened Unscreened | ||
Outer Diameter 7.42mm | ||
Minimum Bend Radius 10 x Cable Diameter | ||
Length 30m | ||
Voltage Rating 300 V | ||
Maximum Operating Temperature +80°C | ||
Core Strands 41/30 AWG | ||
Conductor Resistance 2.8 Ω | ||
Insulation Material PVC | ||
Minimum Operating Temperature -20°C | ||
