Wurth Elektronik 10 μH 5 A Common Mode Choke 0.02 Ω
- RS Stock No.:
- 296-339
- Distrelec Article No.:
- 304-30-048
- Mfr. Part No.:
- 7447054
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 bag of 5 units)*
£7.82
(exc. VAT)
£9.385
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 15 unit(s) shipping from 02 March 2026
- Plus 50 unit(s) shipping from 15 February 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 5 - 45 | £1.564 | £7.82 |
| 50 - 95 | £1.486 | £7.43 |
| 100 - 495 | £1.374 | £6.87 |
| 500 - 995 | £1.268 | £6.34 |
| 1000 + | £1.22 | £6.10 |
*price indicative
- RS Stock No.:
- 296-339
- Distrelec Article No.:
- 304-30-048
- Mfr. Part No.:
- 7447054
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Inductance | 10 μH | |
| Product Type | Common Mode Choke | |
| Series | WE-FI | |
| Maximum DC Current | 5A | |
| Test Frequency | 10 kHz | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Number of Lines | 1 | |
| Automotive Standard | No | |
| Pin Count | 2 | |
| Mount Type | Lead Wire | |
| Inductance Tolerance | ±20 % | |
| Height | 10.5mm | |
| Length | 10.5mm | |
| Termination Style | Solder | |
| Depth | 7.8mm | |
| Maximum DC Resistance | 0.02Ω | |
| Standards/Approvals | IEC 61249-2-21, REACH or declared EC1907, 2006, 863, DIN EN 61760-2, DIN ISO 2768, EU&2015, Halogen Free IEC 61249-2-21, Halogen Free JEDEC JS709B, RoHS 2011 | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Inductance 10 μH | ||
Product Type Common Mode Choke | ||
Series WE-FI | ||
Maximum DC Current 5A | ||
Test Frequency 10 kHz | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Number of Lines 1 | ||
Automotive Standard No | ||
Pin Count 2 | ||
Mount Type Lead Wire | ||
Inductance Tolerance ±20 % | ||
Height 10.5mm | ||
Length 10.5mm | ||
Termination Style Solder | ||
Depth 7.8mm | ||
Maximum DC Resistance 0.02Ω | ||
Standards/Approvals IEC 61249-2-21, REACH or declared EC1907, 2006, 863, DIN EN 61760-2, DIN ISO 2768, EU&2015, Halogen Free IEC 61249-2-21, Halogen Free JEDEC JS709B, RoHS 2011 | ||
- COO (Country of Origin):
- VN
The Wurth Elektronik Leaded Toroidal Line Choke supports current loading up to 9 A with iron powder cores that have low losses. It features a low magnetically leakage field and operates within a temperature range of –25°C to +125°C. Custom designs are available on request.
Application in voltage transformers and power supplies
For interference frequencies up to 10 MHz and switching frequencies up to 100 kHz
Ideal for filtering symmetric interferences
