Moflash A2EX Series Metallic Stainless Steel Cable Gland, M20 Thread, 11mm min., 15mm max., IP66, IP68
- RS Stock No.:
- 901-0668
- Mfr. Part No.:
- 50211
- Brand:
- Moflash
Subtotal (1 unit)*
£52.52
(exc. VAT)
£63.02
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 17 unit(s) ready to ship
- Plus 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £52.52 |
*price indicative
- RS Stock No.:
- 901-0668
- Mfr. Part No.:
- 50211
- Brand:
- Moflash
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Moflash | |
Thread Size | M20 | |
Maximum Cable Diameter | 15mm | |
Minimum Cable Diameter | 11mm | |
Material | Stainless Steel | |
Colour | Metallic | |
Series | A2EX | |
IP Rating | IP66, IP68 | |
Locknut Included | No | |
Hazardous Area Certification | ATEX | |
Maximum Operating Temperature | +95°C | |
Minimum Operating Temperature | -20°C | |
Select all | ||
---|---|---|
Brand Moflash | ||
Thread Size M20 | ||
Maximum Cable Diameter 15mm | ||
Minimum Cable Diameter 11mm | ||
Material Stainless Steel | ||
Colour Metallic | ||
Series A2EX | ||
IP Rating IP66, IP68 | ||
Locknut Included No | ||
Hazardous Area Certification ATEX | ||
Maximum Operating Temperature +95°C | ||
Minimum Operating Temperature -20°C | ||
- COO (Country of Origin):
- SA
A2EX Compression Gland for Explosive Atmospheres
The A2EX Compression Gland is designed for use with unarmoured cable in hazardous areas with a potentially explosive atmosphere. Equipment protection levels: Ex d IIC Gb, Ex e IIC Gb, Ex nR IIC Gc, Ex tb IIIC Db II 2G, II 2D, II 3G.
For indoor, outdoor and hazardous areas for Group II surface installations
Inner seal of seal seals on the cable sheath
Outer seal grips the cable, giving superior cable retention and IP rating
Precision manufactured from high quality brass (marine grade electroless nickel plated) or stainless steel
Complete with a sealing gasket and end cap safety gauge for correct gland selection
IP66 / IP68 protection
Inner seal of seal seals on the cable sheath
Outer seal grips the cable, giving superior cable retention and IP rating
Precision manufactured from high quality brass (marine grade electroless nickel plated) or stainless steel
Complete with a sealing gasket and end cap safety gauge for correct gland selection
IP66 / IP68 protection
Approvals
ATEX, IECEx, INMETRO, SANS/IEC.
