Lapp SKINTOP Series Metallic Nickel Plated Brass Cable Gland, PG21 Thread, 8mm min., 16mm max., IP68
- RS Stock No.:
- 243-8902
- Mfr. Part No.:
- 52003540+52015820
- Brand:
- Lapp
Bulk discount available
Subtotal (1 pack of 5 units)*
£58.21
(exc. VAT)
£69.85
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 260 unit(s) ready to ship
- Plus 70 unit(s) ready to ship from another location
- Plus 999,999,735 unit(s) shipping from 01 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 20 | £11.642 | £58.21 |
| 25 - 45 | £11.07 | £55.35 |
| 50 + | £10.476 | £52.38 |
*price indicative
- RS Stock No.:
- 243-8902
- Mfr. Part No.:
- 52003540+52015820
- Brand:
- Lapp
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Lapp | |
| Thread Size | PG21 | |
| Maximum Cable Diameter | 16mm | |
| Minimum Cable Diameter | 8mm | |
| Material | Nickel Plated Brass | |
| Colour | Metallic | |
| Series | SKINTOP | |
| IP Rating | IP68 | |
| Locknut Included | Yes | |
| Fire Behaviour | Flame Retardant, Halogen Free | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | +100°C | |
| Number of Pieces | 75 | |
| Standards Met | CE, RoHS Compliant | |
| Operating Temperature Range | -30 → +100 °C | |
| Kit Includes | Cable Glands, Counter Nuts | |
| Reference | SKINTOP MSR | |
Select all | ||
|---|---|---|
Brand Lapp | ||
Thread Size PG21 | ||
Maximum Cable Diameter 16mm | ||
Minimum Cable Diameter 8mm | ||
Material Nickel Plated Brass | ||
Colour Metallic | ||
Series SKINTOP | ||
IP Rating IP68 | ||
Locknut Included Yes | ||
Fire Behaviour Flame Retardant, Halogen Free | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature +100°C | ||
Number of Pieces 75 | ||
Standards Met CE, RoHS Compliant | ||
Operating Temperature Range -30 → +100 °C | ||
Kit Includes Cable Glands, Counter Nuts | ||
Reference SKINTOP MSR | ||
- COO (Country of Origin):
- DE
LAPP Cable Gland, PG7 Connecting Thread, IP68 Rating - SKINTOP Series - 52003540+52015820
For a wire attachment that can roll with the punches, choose this cable gland from LAPP. It tightens the end of your cable to a port, making sure it holds fast in the face of vibration. To really seal the deal, the unit comes with a CR sealing ring and an NBR O-ring that work together to keep out dirt and moisture particles, keeping the gland's interior spick and span. Chemicals, corrosion and overheating aren't a problem, thanks to its durable nickel-plated brass body.
Features & Benefits
• Comes with locknut for added security
• Threaded design enables quick, screw-on mounting
• Integrated strain relief helps prevent cable wear and tear
• Threaded design enables quick, screw-on mounting
• Integrated strain relief helps prevent cable wear and tear
Applications
• Chemical plants
• Electrical engineering
• Medical and pharmaceutical industry
• Electrical engineering
• Medical and pharmaceutical industry
What wire sizes can I fit into this cable gland?
You can fit wires that range in diameter from 8 to 16mm, making it suitable for your small and medium-sized electrical connections.
