TE Connectivity Uninsulated DIMM Socket, 0.5mm² to 2.27mm², 20AWG to 14AWG, 5mm Bullet diameter Male
- RS Stock No.:
- 719-6221
- Mfr. Part No.:
- 170003-4
- Brand:
- TE Connectivity
Currently unavailable
We don’t know if this item will be back in stock, it is being discontinued by the manufacturer.
- RS Stock No.:
- 719-6221
- Mfr. Part No.:
- 170003-4
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Insulation | Uninsulated | |
| Overall Length | 19.6mm | |
| Gender | Male | |
| Minimum Wire Size mm² | 0.5mm² | |
| Maximum Wire Size mm² | 2.27mm² | |
| Minimum Wire Size AWG | 20AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Bullet Diameter | 5mm | |
| Shrouded/Unshrouded | Unshrouded | |
| Contact Plating | Tin | |
| Contact Material | Brass | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Insulation Uninsulated | ||
Overall Length 19.6mm | ||
Gender Male | ||
Minimum Wire Size mm² 0.5mm² | ||
Maximum Wire Size mm² 2.27mm² | ||
Minimum Wire Size AWG 20AWG | ||
Maximum Wire Size AWG 14AWG | ||
Bullet Diameter 5mm | ||
Shrouded/Unshrouded Unshrouded | ||
Contact Plating Tin | ||
Contact Material Brass | ||
TE Connectivity SHUR-PLUG Bullet Receptacle Terminals
SHUR-PLUG bullet crimp receptacle terminals made from brass with a variety of platings. These SHUR-PLUG bullet receptacle connectors are for use with SHUR-PLUG bullet plug crimp terminals with a 3.96mm pin diameter apart from stock number 795-6449 which is for use with a 4.57mm diameter SHUR-PLUG bullet connector.
Shur Plugs and Shur Plug Receptacles
