onsemi Bridge Rectifier, 35A, 200V, 4-Pin
- RS Stock No.:
- 903-4245
- Mfr. Part No.:
- GBPC3502
- Brand:
- onsemi
45 In stock - FREE next working day delivery available
30 available from Europe for delivery within 1 working day(s).
Price Each (In a Pack of 5)
£5.25
(exc. VAT)
£6.30
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 5 + | £5.25 | £26.25 |
*price indicative
- RS Stock No.:
- 903-4245
- Mfr. Part No.:
- GBPC3502
- Brand:
- onsemi
Technical Reference
Legislation and Compliance
Product Details
Bridge Rectifiers with Push-on Terminals, GBPC 35 Series, Fairchild Semiconductor
High Current 35 Amperes
Glass Passivated junction
Integrally molded heat-sink provided very low thermal resistance for maximum heat dissipation
Fast-on Terminals
Glass Passivated junction
Integrally molded heat-sink provided very low thermal resistance for maximum heat dissipation
Fast-on Terminals
Approvals
UL E-258596
Specifications
Attribute | Value |
|---|---|
| Bridge Type | Single Phase |
| Peak Average Forward Current | 35A |
| Peak Reverse Repetitive Voltage | 200V |
| Mounting Type | Through Hole |
| Package Type | GBPC 4L |
| Pin Count | 4 |
| Diode Technology | Silicon Junction |
| Configuration | Single |
| Peak Non-Repetitive Forward Surge Current | 400A |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -55 °C |
| Peak Forward Voltage | 1.1V |
| Peak Reverse Current | 5µA |
| Length | 29mm |
| Dimensions | 29 x 29 x 11.23mm |
| Junction Capacitance | 200pF |
| Width | 29mm |
| Height | 11.23mm |
