- RS Stock No.:
- 801-0070
- Mfr. Part No.:
- DTC114TET1G
- Brand:
- onsemi
500 In stock - FREE next working day delivery available
Added
Price Each (On a Tape of 250)
£0.017
(exc. VAT)
£0.02
(inc. VAT)
Units | Per unit | Per Tape* |
250 + | £0.017 | £4.25 |
*price indicative |
- RS Stock No.:
- 801-0070
- Mfr. Part No.:
- DTC114TET1G
- Brand:
- onsemi
Technical Reference
Legislation and Compliance
Product Details
Single Resistor Digital Transistors, ON Semiconductor
Standards
Manufacturer Part Nos with S or NSV prefix are automotive qualified to AEC-Q101 standard.
Digital Transistors, ON Semiconductor
Resistor-equipped bipolar transistors, also known as Digital Transistors or Bias Resistor Transistors, incorporating one or two integrated resistors. A single series input resistor, or a potential divider of two resistors, allows these devices to be directly driven from digital sources. Both single and dual transistor versions are available.
Specifications
Attribute | Value |
---|---|
Transistor Type | NPN |
Maximum DC Collector Current | 100 mA |
Maximum Collector Emitter Voltage | 50 V |
Package Type | SOT-416 (SC-75) |
Mounting Type | Surface Mount |
Maximum Power Dissipation | 300 mW |
Transistor Configuration | Single |
Maximum Emitter Base Voltage | 6 V |
Pin Count | 3 |
Number of Elements per Chip | 1 |
Typical Input Resistor | 10 kΩ |
Typical Resistor Ratio | None |
Dimensions | 1.65 x 0.9 x 0.8mm |
Maximum Operating Temperature | +150 °C |
