Nexperia PUMD18,115 Dual NPN/PNP Digital Transistor, 100 mA, 50 V, 6-Pin SOT-363

View all Bipolar Transistors
Bulk discount available

Subtotal (1 pack of 250 units)*

£16.25

(exc. VAT)

£19.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1,750 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
250 - 250£0.065£16.25
500 - 1000£0.049£12.25
1250 - 2250£0.039£9.75
2500 +£0.035£8.75

*price indicative

RS Stock No.:
151-2773
Mfr. Part No.:
PUMD18,115
Brand:
Nexperia
Find similar products by selecting one or more attributes.
Select all

Brand

Nexperia

Transistor Type

NPN/PNP

Maximum DC Collector Current

100 mA

Maximum Collector Emitter Voltage

50 V

Package Type

SOT-363

Mounting Type

Surface Mount

Maximum Power Dissipation

300 mW

Transistor Configuration

Dual

Pin Count

6

Number of Elements per Chip

2

Typical Input Resistor

4.7 kΩ

Base-Emitter Resistor

10kΩ

Typical Resistor Ratio

2.1

Maximum Operating Temperature

+150 °C

Dimensions

2.2 x 1.35 x 1.1mm

COO (Country of Origin):
MY
Resistor Equipped Transistors (RETs), Space and cost-saving solutions that reduce component count and simplify circuit design.

NPN/PNP resistor-equipped transistors, R1 = 4.7 kΩ, R2 = 10 kΩ, NPN/PNP double Resistor-Equipped Transistors (RET) in Surface-Mounted Device (SMD) plastic packages.

105 mA output current capability
Built-in bias resistors
Simplified circuit design
Reduces component count
