SKF 3205 A-2RS1/C3 Double Row Angular Contact Ball Bearing- Both Sides Sealed 25mm I.D, 52mm O.D
- RS Stock No.:
- 207-9857
- Mfr. Part No.:
- 3205 A-2RS1/C3
- Brand:
- SKF
Subtotal (1 unit)*
£57.66
(exc. VAT)
£69.19
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 174 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £57.66 |
*price indicative
- RS Stock No.:
- 207-9857
- Mfr. Part No.:
- 3205 A-2RS1/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 25mm | |
Outside Diameter | 52mm | |
Race Width | 20.6mm | |
Ball Bearing Type | Double Row Angular Contact Ball Bearing | |
Sealing Arrangement | Both Sides Sealed | |
Bearing Clearance | C3 | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Sheet Metal | |
Number of Rows | 2 | |
Static Load Rating | 15.3kN | |
Dynamic Load Rating | 22kN | |
Clearance Code | C3 | |
Bore Type | Parallel | |
Bearing Series | 2 Light | |
Model Number p | 3205 | |
Partial Bearing Code | 3205 | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 25mm | ||
Outside Diameter 52mm | ||
Race Width 20.6mm | ||
Ball Bearing Type Double Row Angular Contact Ball Bearing | ||
Sealing Arrangement Both Sides Sealed | ||
Bearing Clearance C3 | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
Number of Rows 2 | ||
Static Load Rating 15.3kN | ||
Dynamic Load Rating 22kN | ||
Clearance Code C3 | ||
Bore Type Parallel | ||
Bearing Series 2 Light | ||
Model Number p 3205 | ||
Partial Bearing Code 3205 | ||
- COO (Country of Origin):
- DE
SKF Ball Bearing, 25mm Inside Diameter, 52mm Outside Diameter - 3205 A-2RS1/C3
This ball bearing is crafted for challenging applications across various mechanical and electrical systems. With a robust construction and sealed design, it ensures a high level of performance and durability. The double-row angular contact configuration effectively accommodates both radial and axial loads, making it valuable for users in the automation and electronics sectors.
Features & Benefits
• Enhanced load capacity due to the double-row design
• Sealed on both sides to prevent contamination
• Suitable for high-speed applications with minimal friction
• C3 bearing clearance for extended operational lifespan
• Manufactured from steel for durability and strength
• Designed to handle high dynamic loads efficiently
• Sealed on both sides to prevent contamination
• Suitable for high-speed applications with minimal friction
• C3 bearing clearance for extended operational lifespan
• Manufactured from steel for durability and strength
• Designed to handle high dynamic loads efficiently
Applications
• Utilised in robotics and automation equipment
• Suitable for high-performance electric motors
• Employed in conveyor systems for dependable operation
• Applicable in precision machinery where accuracy is critical
• Suitable for high-performance electric motors
• Employed in conveyor systems for dependable operation
• Applicable in precision machinery where accuracy is critical
What maintenance is required to keep it functioning optimally?
Regular cleaning and lubrication are recommended to maintain performance, especially in dusty environments.
How does the sealing arrangement affect performance?
The dual sealing prevents contamination ingress, enhancing lifespan and reliability in challenging conditions.
Is it suitable for high-speed applications?
Yes, its design supports high-speed rotation effectively, ensuring smooth operation.
What load ratings should I consider for my application?
Both static and dynamic load ratings should be considered to ensure suitability for your specific operational requirements.
Can it be used in varying temperature conditions?
It is advisable to check the operating temperature limits to achieve optimal performance in extreme conditions.
