SKF 6206-Z/C3 Single Row Deep Groove Ball Bearing- One Side Shielded 30mm I.D, 62mm O.D
- RS Stock No.:
- 207-6662
- Mfr. Part No.:
- 6206-Z/C3
- Brand:
- SKF
Subtotal (1 unit)*
£19.77
(exc. VAT)
£23.72
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 7 unit(s) ready to ship
- Plus 7 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £19.77 |
*price indicative
- RS Stock No.:
- 207-6662
- Mfr. Part No.:
- 6206-Z/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 30mm | |
Outside Diameter | 62mm | |
Race Width | 16mm | |
Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
Sealing Arrangement | One Side Shielded | |
Bearing Clearance | C3 | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Sheet Metal | |
Number of Rows | 1 | |
Static Load Rating | 11.2kN | |
Dynamic Load Rating | 20.3kN | |
Bore Type | Parallel | |
Clearance Code | C3 | |
Bearing Series | 2 Light | |
Model Number p | 6206-Z/C3 | |
Partial Bearing Code | 6206 | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 30mm | ||
Outside Diameter 62mm | ||
Race Width 16mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement One Side Shielded | ||
Bearing Clearance C3 | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
Number of Rows 1 | ||
Static Load Rating 11.2kN | ||
Dynamic Load Rating 20.3kN | ||
Bore Type Parallel | ||
Clearance Code C3 | ||
Bearing Series 2 Light | ||
Model Number p 6206-Z/C3 | ||
Partial Bearing Code 6206 | ||
SKF Deep Groove Ball Bearing, 62mm Outside Diameter, 20.3 kN Dynamic Load Rating - 6206-Z/C3
Yes, it supports a static load rating of 11.2kN.
Features & Benefits
• Shielded design reduces contamination and maintenance needs
• Steel construction ensures durability and high load capacity
• Dynamic load rating of 20.3kN for efficient operation
• Cylindrical bore type promotes easy installation
• Steel construction ensures durability and high load capacity
• Dynamic load rating of 20.3kN for efficient operation
• Cylindrical bore type promotes easy installation
Applications
• Used in electric motors where efficient rotation is necessary
• Suitable for conveyor systems requiring low friction
• Ideal for pumps that need consistent performance under load
• Commonly employed in fans for effective airflow management
• Suitable for conveyor systems requiring low friction
• Ideal for pumps that need consistent performance under load
• Commonly employed in fans for effective airflow management
Can it handle high static loads?
Yes, it supports a static load rating of 11.2kN.
Is it suitable for use in contaminated environments?
Yes, the shielded design helps prevent debris ingress.
Will it operate efficiently at varying temperatures?
Yes, the C3 clearance allows for thermal expansion adjustments.
