SKF 6005-2RSLTN9/C3VT162 Single Row Deep Groove Ball Bearing- Both Sides Sealed 25mm I.D, 47mm O.D
- RS Stock No.:
- 123-4846
- Mfr. Part No.:
- 6005-2RSLTN9/C3VT162
- Brand:
- SKF
Save 8% when you buy 25 units
Subtotal (1 unit)*
£13.15
(exc. VAT)
£15.78
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 35 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £13.15 |
5 - 9 | £12.64 |
10 - 24 | £12.37 |
25 + | £12.09 |
*price indicative
- RS Stock No.:
- 123-4846
- Mfr. Part No.:
- 6005-2RSLTN9/C3VT162
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 25mm | |
Outside Diameter | 47mm | |
Race Width | 12mm | |
Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
Sealing Arrangement | Both Sides Sealed | |
Bearing Clearance | C3 | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Non-metallic | |
Number of Rows | 1 | |
Static Load Rating | 6.55kN | |
Dynamic Load Rating | 11.9kN | |
Bore Type | Parallel | |
Bearing Series | 0 Extra Light | |
Partial Bearing Code | 6005 | |
Race Type | Plain | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 25mm | ||
Outside Diameter 47mm | ||
Race Width 12mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement Both Sides Sealed | ||
Bearing Clearance C3 | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Non-metallic | ||
Number of Rows 1 | ||
Static Load Rating 6.55kN | ||
Dynamic Load Rating 11.9kN | ||
Bore Type Parallel | ||
Bearing Series 0 Extra Light | ||
Partial Bearing Code 6005 | ||
Race Type Plain | ||
- COO (Country of Origin):
- IT
SKF Ball Bearing, Deep Groove, Plain Race, 25mm ID, 47mm OD - 6005-2RSLTN9/C3VT162
Choose this deep-groove ball bearing from SKF to support the smooth operation of rotating equipment. It's capable of high rotational speeds with minimal friction, which helps maintain a cool operating temperature. To stop dirt and airborne contaminates from entering the bearing, it's sealed on both ends. These seals also trap in lubricant to minimise the need for regreasing. For reliable resistance to corrosion, the component's raceways are made from steel. This means it can be used safely in areas where regular washdowns take place.
• Accepts both radial and axial loads in either direction for versatility
• Robust fibreglass-reinforced nylon cage retains its dimensional stability in harsh operating conditions
• Reduced environmental impact, thanks to its efficient use of lubricant
• Rolling elements are manufactured to close tolerances to reduce vibration and assist with equalisation of load distribution
• Robust fibreglass-reinforced nylon cage retains its dimensional stability in harsh operating conditions
• Reduced environmental impact, thanks to its efficient use of lubricant
• Rolling elements are manufactured to close tolerances to reduce vibration and assist with equalisation of load distribution
Applications
• Wind turbines
• Wastewater management systems
• Mining and minerals processing
• Marine and offshore industries
• Wastewater management systems
• Mining and minerals processing
• Marine and offshore industries
What benefits do SKF Explorer bearings have?
Like all components in the SKF Explorer range, this bearing has an optimised internal geometry to reduce friction, heat generation and wear.
Deep Groove Ball Bearings
