SKF 3309 DMA 2 Row Angular Contact Ball Bearing - 45 mm ID, 100 mm OD 39.7 mm Race Width
- RS Stock No.:
- 461-838
- Mfr. Part No.:
- 3309 DMA
- Brand:
- SKF
Subtotal (1 unit)*
£403.63
(exc. VAT)
£484.36
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 02 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £403.63 |
*price indicative
- RS Stock No.:
- 461-838
- Mfr. Part No.:
- 3309 DMA
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 45 mm | |
| Product Type | Angular Contact Ball Bearing | |
| Outside Diameter | 100 mm | |
| Race Width | 39.7mm | |
| Cage Material | Machined Metal | |
| Race Material | Steel | |
| Ball Material | Steel | |
| End Type | Open | |
| Number of Rows | 2 | |
| Static Load Rating | 69.5kN | |
| Internal Clearance | CN | |
| Contact Angle | 45° | |
| Dynamic Load Rating | 79.3kN | |
| Standards/Approvals | RoHS | |
| Series | 3309 | |
| Limiting Speed | 6300rpm | |
| Race Type | Grooved | |
| Bearing Type | Angular Contact | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 45 mm | ||
Product Type Angular Contact Ball Bearing | ||
Outside Diameter 100 mm | ||
Race Width 39.7mm | ||
Cage Material Machined Metal | ||
Race Material Steel | ||
Ball Material Steel | ||
End Type Open | ||
Number of Rows 2 | ||
Static Load Rating 69.5kN | ||
Internal Clearance CN | ||
Contact Angle 45° | ||
Dynamic Load Rating 79.3kN | ||
Standards/Approvals RoHS | ||
Series 3309 | ||
Limiting Speed 6300rpm | ||
Race Type Grooved | ||
Bearing Type Angular Contact | ||
- COO (Country of Origin):
- AT
Gavin
The SKF Double row angular contact ball bearings correspond, in their design and operation, to a pair of single row angular contact ball bearings in a back-to-back arrangement, while requiring less axial space, and are particularly suitable in applications where a stiff bearing arrangement is required. They can accommodate radial loads, axial loads in either direction and tilting moments. They can operate at very high speeds and are more suitable than deep groove ball bearings for supporting large axial forces.
Accommodate relatively high radial loads and large axial loads in both directions
Suitable where a stiff bearing arrangement is required
Require less axial space than equivalent pair of single row angular contact ball bearings
