SKF 1204 EKTN9 20 mm ID 2 Row Self-Aligning Ball Bearing -, 47 mm OD
- RS Stock No.:
- 461-451
- Mfr. Part No.:
- 1204 EKTN9
- Brand:
- SKF
Subtotal (1 unit)*
£51.61
(exc. VAT)
£61.93
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £51.61 |
*price indicative
- RS Stock No.:
- 461-451
- Mfr. Part No.:
- 1204 EKTN9
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Self-Aligning Ball Bearing | |
| Inside Diameter | 20 mm | |
| Outside Diameter | 47 mm | |
| Race Width | 14mm | |
| Cage Material | Non-Metallic | |
| Ball Material | Bearing Steel | |
| Number of Rows | 2 | |
| Static Load Rating | 3.4kN | |
| Internal Clearance | CN | |
| Dynamic Load Rating | 12.7kN | |
| Series | 1204 EKTN9 | |
| Standards/Approvals | RoHS | |
| Bore Type | Tapered 1:12 | |
| Limiting Speed | 20000rpm | |
| Bearing Type | Self-aligning Ball Bearing | |
| Flange Outside Diameter | 47mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Self-Aligning Ball Bearing | ||
Inside Diameter 20 mm | ||
Outside Diameter 47 mm | ||
Race Width 14mm | ||
Cage Material Non-Metallic | ||
Ball Material Bearing Steel | ||
Number of Rows 2 | ||
Static Load Rating 3.4kN | ||
Internal Clearance CN | ||
Dynamic Load Rating 12.7kN | ||
Series 1204 EKTN9 | ||
Standards/Approvals RoHS | ||
Bore Type Tapered 1:12 | ||
Limiting Speed 20000rpm | ||
Bearing Type Self-aligning Ball Bearing | ||
Flange Outside Diameter 47mm | ||
- COO (Country of Origin):
- CH
Rupali
The SKF Self aligning ball bearings, with a tapered bore, have two rows of balls, a common sphered raceway in the outer ring and two deep uninterrupted raceway grooves in the inner ring. They are insensitive to angular misalignment of the shaft relative to the housing, which can be caused, for example, by shaft deflection. The tapered bore facilitates ease of mounting via adapter sleeves or withdrawal sleeves.
Ease of mounting via adapter sleeves or withdrawal sleeves
Accommodate static and dynamic misalignment
Excellent high speed performance
Excellent light load performance
Low friction
