CHEMI-CON 470μF Aluminium Electrolytic Capacitor 500V dc, Snap-In - ELXS501VSN471MA60S
- RS Stock No.:
- 914-3765
- Mfr. Part No.:
- ELXS501VSN471MA60S
- Brand:
- CHEMI-CON
Bulk discount available
Subtotal (1 unit)*
£16.23
(exc. VAT)
£19.48
(inc. VAT)
FREE delivery for orders over £50.00
Last RS stock
- Final 2 unit(s), ready to ship
Units | Per unit |
|---|---|
| 1 - 9 | £16.23 |
| 10 - 24 | £15.40 |
| 25 - 99 | £13.86 |
| 100 - 199 | £13.51 |
| 200 + | £13.18 |
*price indicative
- RS Stock No.:
- 914-3765
- Mfr. Part No.:
- ELXS501VSN471MA60S
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 470µF | |
| Voltage | 500V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 35 (Dia.) x 60mm | |
| Length | 60mm | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 35mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 5000h | |
| Lead Pitch | 10mm | |
| Leakage Current | <=3√CV μA @ 5 min | |
| Series | LXS | |
| Ripple Current | 2.03Arms | |
| Tolerance | ±20% | |
| Dissipation Factor | 0.2% | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 470µF | ||
Voltage 500V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 35 (Dia.) x 60mm | ||
Length 60mm | ||
Minimum Operating Temperature -25°C | ||
Diameter 35mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 5000h | ||
Lead Pitch 10mm | ||
Leakage Current <=3√CV μA @ 5 min | ||
Series LXS | ||
Ripple Current 2.03Arms | ||
Tolerance ±20% | ||
Dissipation Factor 0.2% | ||
Nippon Chemi-Con Al Snap-in Capacitors, LXS Series
Long Life Large Capacitance Aluminium Electrolytic Capacitors, LXS Series
Endurance with Ripple Current: 5000 hours at 105℃
Rated voltage range: 160 V to 500 V
Downsized from LXQ series
Non-solvent resistant type
Ideal for Solar Power Generation
Rated voltage range: 160 V to 500 V
Downsized from LXQ series
Non-solvent resistant type
Ideal for Solar Power Generation
