Wurth Elektronik 330μF Aluminium Electrolytic Capacitor 6.3V dc, Surface Mount - 865250153008
- RS Stock No.:
- 839-5182
- Mfr. Part No.:
- 865250153008
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 pack of 5 units)*
£4.79
(exc. VAT)
£5.75
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 45 | £0.958 | £4.79 |
| 50 - 95 | £0.824 | £4.12 |
| 100 - 245 | £0.748 | £3.74 |
| 250 - 495 | £0.65 | £3.25 |
| 500 + | £0.556 | £2.78 |
*price indicative
- RS Stock No.:
- 839-5182
- Mfr. Part No.:
- 865250153008
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Capacitance | 330µF | |
| Voltage | 6.3V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 10.5 (Dia.) x 7.85mm | |
| Height | 7.85mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 10.5mm | |
| Maximum Operating Temperature | +85°C | |
| Lifetime | 2000h | |
| Lead Pitch | 3.1mm | |
| Leakage Current | 103.95 μA | |
| Series | WCAP-ASNP | |
| Tolerance | ±20% | |
| Ripple Current | 160mA | |
| Polarised | Polar | |
| Dissipation Factor | 24 | |
Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Capacitance 330µF | ||
Voltage 6.3V dc | ||
Mounting Type Surface Mount | ||
Technology Aluminium Electrolytic | ||
Dimensions 10.5 (Dia.) x 7.85mm | ||
Height 7.85mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 10.5mm | ||
Maximum Operating Temperature +85°C | ||
Lifetime 2000h | ||
Lead Pitch 3.1mm | ||
Leakage Current 103.95 μA | ||
Series WCAP-ASNP | ||
Tolerance ±20% | ||
Ripple Current 160mA | ||
Polarised Polar | ||
Dissipation Factor 24 | ||
Wurth Elektronik SMD Non-Polar WCAP-ASNP Series Capacitors
WCAP-ASNP are non-polarised Aluminium Electrolytic Capacitor Series
Features and Benefits
• Load life: 2000 h @ +85°C
• Operating temperature: -40°C to +85°C
• Reflow soldering recommended
• Operating temperature: -40°C to +85°C
• Reflow soldering recommended
