Panasonic 47μF Aluminium Electrolytic Aluminium Electrolytic Capacitor 16V dc, Surface Mount - EEEFK1C470UR
- RS Stock No.:
- 537-0461P
- Mfr. Part No.:
- EEEFK1C470UR
- Brand:
- Panasonic
Bulk discount available
Subtotal 50 units (supplied on a reel)*. Quantities below 150 on continuous strip
£18.40
(exc. VAT)
£22.10
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 38,525 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 50 - 95 | £0.368 |
| 100 - 245 | £0.346 |
| 250 - 495 | £0.32 |
| 500 + | £0.292 |
*price indicative
- RS Stock No.:
- 537-0461P
- Mfr. Part No.:
- EEEFK1C470UR
- Brand:
- Panasonic
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Panasonic | |
| Capacitance | 47µF | |
| Voltage | 16V dc | |
| Mounting Type | Surface Mount | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 5 (Dia.) x 5.8mm | |
| Height | 5.8mm | |
| Length | 5.8mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 5mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 2000h | |
| Lead Pitch | 1.5mm | |
| Leakage Current | 7.5 μA | |
| Polarised | Polar | |
| Automotive Standard | AEC-Q200 | |
| Series | FK | |
| Tolerance | ±20% | |
| Ripple Current | 160mA | |
| Equivalent Series Resistance | 700mΩ | |
| Dissipation Factor | 200% | |
