Vishay 150 μF Capacitor 450V dc, Snap-in - MAL215947151E3
- RS Stock No.:
- 280-6795
- Mfr. Part No.:
- MAL215947151E3
- Brand:
- Vishay
Subtotal (1 box of 100 units)*
£764.30
(exc. VAT)
£917.20
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 700 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Box* |
|---|---|---|
| 100 + | £7.643 | £764.30 |
*price indicative
- RS Stock No.:
- 280-6795
- Mfr. Part No.:
- MAL215947151E3
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Capacitor | |
| Capacitance | 150μF | |
| Voltage | 450V dc | |
| Mount Type | Snap-in | |
| Construction | Cylindrical Can | |
| Packaging | Box | |
| Polarity | Polar | |
| Minimum Operating Temperature | -25°C | |
| Diameter | 25mm | |
| Termination Type | Snap-In | |
| Capacitor Ripple Current | 950mA | |
| Pin Count | 3 | |
| Maximum Operating Temperature | 105°C | |
| Lifetime | 5000 h | |
| Standards/Approvals | IEC 60068, IEC 60384-4/EN 130300 | |
| Equivalent Series Resistance ESR | 600mΩ | |
| Automotive Standard | No | |
| Series | 159 PUL-SI | |
| Tolerance | ±20 % | |
| Leakage Current | 670μA | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Capacitor | ||
Capacitance 150μF | ||
Voltage 450V dc | ||
Mount Type Snap-in | ||
Construction Cylindrical Can | ||
Packaging Box | ||
Polarity Polar | ||
Minimum Operating Temperature -25°C | ||
Diameter 25mm | ||
Termination Type Snap-In | ||
Capacitor Ripple Current 950mA | ||
Pin Count 3 | ||
Maximum Operating Temperature 105°C | ||
Lifetime 5000 h | ||
Standards/Approvals IEC 60068, IEC 60384-4/EN 130300 | ||
Equivalent Series Resistance ESR 600mΩ | ||
Automotive Standard No | ||
Series 159 PUL-SI | ||
Tolerance ±20 % | ||
Leakage Current 670μA | ||
The Vishay aluminium electrolytic capacitor has power ultra long life snap in terminals. It is used for general purpose, industrial and audio or video systems applications, it has low ESR and high ripple current capability.
High reliability
Long life and insulated
