Nichicon 47 μF Capacitor 35V dc, Surface Surface Mount
- RS Stock No.:
- 222-9633
- Mfr. Part No.:
- UUR1V470MCL6GS
- Brand:
- Nichicon
Subtotal (5000 units, on reels of 5000)*
£220.00
(exc. VAT)
£265.00
(inc. VAT)
FREE delivery for orders over £60.00
Last RS stock
- Final 10,000 unit(s), ready to ship
Units | Per unit | Per Reel* |
|---|---|---|
| 5000 + | £0.044 | £220.00 |
*price indicative
- RS Stock No.:
- 222-9633
- Mfr. Part No.:
- UUR1V470MCL6GS
- Brand:
- Nichicon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Nichicon | |
| Product Type | Capacitor | |
| Capacitance | 47μF | |
| Voltage | 35V dc | |
| Mount Type | Surface | |
| Construction | Chip Type | |
| Length | 5.8mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 6.3mm | |
| Pin Count | 2 | |
| Termination Type | Surface Mount | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | 863, AEC-Q200, EU, EU 2015, RoHS 2011 | |
| Series | UUR | |
| Leakage Current | 0μA | |
| Tolerance ± | 20% | |
| Ripple Current | 94mA | |
| Automotive Standard | AEC-Q200 | |
| Dissipation Factor | 0.12% | |
| Select all | ||
|---|---|---|
Brand Nichicon | ||
Product Type Capacitor | ||
Capacitance 47μF | ||
Voltage 35V dc | ||
Mount Type Surface | ||
Construction Chip Type | ||
Length 5.8mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 6.3mm | ||
Pin Count 2 | ||
Termination Type Surface Mount | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals 863, AEC-Q200, EU, EU 2015, RoHS 2011 | ||
Series UUR | ||
Leakage Current 0μA | ||
Tolerance ± 20% | ||
Ripple Current 94mA | ||
Automotive Standard AEC-Q200 | ||
Dissipation Factor 0.12% | ||
The Nichicon UUR series is a Chip type aluminium electrolytic capacitor which have rated capacitance of 47 μF with capacitance tolerance of ± 20%.It is ideally designed for surface mounting on high density PC board and applicable to automatic mounting machine fed with carrier tape
Compliant to the RoHS directive.
AEC-Q200 compliant.
Applicable to automatic mounting machine fed with carrier tape.
