- RS Stock No.:
- 171-3205
- Mfr. Part No.:
- B41231C4229M000
- Brand:
- EPCOS
400 In stock - FREE next working day delivery available
Added
Price Each (In a Box of 80)
£1.40
(exc. VAT)
£1.68
(inc. VAT)
Units | Per unit | Per Box* |
80 - 320 | £1.40 | £112.00 |
400 + | £1.344 | £107.52 |
*price indicative |
- RS Stock No.:
- 171-3205
- Mfr. Part No.:
- B41231C4229M000
- Brand:
- EPCOS
Technical Reference
Legislation and Compliance
Product Details
Applications:
Professional power supplies
Features:
High ripple current capability
Useful life of 2000 h at 85 °C
Construction:
Aluminium case, fully insulated with PET or PVC
Snap-in solder pins to hold component in place on PC-board
Minus pole marking on the insulating sleeve
Case with safety vent on the base
Professional power supplies
Features:
High ripple current capability
Useful life of 2000 h at 85 °C
Construction:
Aluminium case, fully insulated with PET or PVC
Snap-in solder pins to hold component in place on PC-board
Minus pole marking on the insulating sleeve
Case with safety vent on the base
Specifications
Attribute | Value |
---|---|
Capacitance | 22000µF |
Voltage | 16V dc |
Mounting Type | Snap-In |
Technology | Aluminium Electrolytic |
Dimensions | 30 (Dia.) x 30mm |
Height | 30mm |
Minimum Operating Temperature | -40°C |
Diameter | 30mm |
Maximum Operating Temperature | +85°C |
Lead Pitch | 10mm |
Lifetime | 2000h |
Tolerance | ±20% |
Ripple Current | 5.39A |
Polarised | Polar |
Series | B41231 |
Dissipation Factor | 0.5% |
