CHEMI-CON 470μF Aluminium Electrolytic Capacitor 16V dc, Snap-In - EKMQ160ELL471MHB5D
- RS Stock No.:
- 144-7354
- Mfr. Part No.:
- EKMQ160ELL471MHB5D
- Brand:
- CHEMI-CON
Unavailable
RS will no longer stock this product.
- RS Stock No.:
- 144-7354
- Mfr. Part No.:
- EKMQ160ELL471MHB5D
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 470µF | |
| Voltage | 16V dc | |
| Mounting Type | Snap-In | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 8.5 (Dia.) x 13mm | |
| Height | 13mm | |
| Minimum Operating Temperature | -55°C | |
| Diameter | 8.5mm | |
| Maximum Operating Temperature | +105°C | |
| Lifetime | 2000h | |
| Lead Pitch | 3.5mm | |
| Ripple Current | 315mArms | |
| Leakage Current | 4 μA | |
| Polarised | Polar | |
| Tolerance | ±20% | |
| Series | KMQ | |
| Dissipation Factor | 0.2% | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 470µF | ||
Voltage 16V dc | ||
Mounting Type Snap-In | ||
Technology Aluminium Electrolytic | ||
Dimensions 8.5 (Dia.) x 13mm | ||
Height 13mm | ||
Minimum Operating Temperature -55°C | ||
Diameter 8.5mm | ||
Maximum Operating Temperature +105°C | ||
Lifetime 2000h | ||
Lead Pitch 3.5mm | ||
Ripple Current 315mArms | ||
Leakage Current 4 μA | ||
Polarised Polar | ||
Tolerance ±20% | ||
Series KMQ | ||
Dissipation Factor 0.2% | ||
- COO (Country of Origin):
- JP
Downsized from current standard KMG series
Solvent resistant type except 160 to 450Vdc
(see PRECAUTIONS AND GUIDELINES)
RoHS2 Compliant
Solvent resistant type except 160 to 450Vdc
(see PRECAUTIONS AND GUIDELINES)
RoHS2 Compliant
