CHEMI-CON 100μF Aluminium Electrolytic Capacitor 35V dc, Through Hole - ESMQ350ELL101MF11D
- RS Stock No.:
- 146-8545
- Mfr. Part No.:
- ESMQ350ELL101MF11D
- Brand:
- CHEMI-CON
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each (In a Pack of 5)
£0.192
(exc. VAT)
£0.23
(inc. VAT)
- RS Stock No.:
- 146-8545
- Mfr. Part No.:
- ESMQ350ELL101MF11D
- Brand:
- CHEMI-CON
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | CHEMI-CON | |
| Capacitance | 100µF | |
| Voltage | 35V dc | |
| Mounting Type | Through Hole | |
| Technology | Aluminium Electrolytic | |
| Dimensions | 6.8 (Dia.) x 12.5mm | |
| Height | 12.5mm | |
| Minimum Operating Temperature | -40°C | |
| Diameter | 6.8mm | |
| Maximum Operating Temperature | +85°C | |
| Lifetime | 2000h | |
| Lead Pitch | 2.5mm | |
| Polarised | Polar | |
| Leakage Current | 4 μA | |
| Series | SMQ | |
| Ripple Current | 210mArms | |
| Tolerance | ±20% | |
| Dissipation Factor | 0.14% | |
Select all | ||
|---|---|---|
Brand CHEMI-CON | ||
Capacitance 100µF | ||
Voltage 35V dc | ||
Mounting Type Through Hole | ||
Technology Aluminium Electrolytic | ||
Dimensions 6.8 (Dia.) x 12.5mm | ||
Height 12.5mm | ||
Minimum Operating Temperature -40°C | ||
Diameter 6.8mm | ||
Maximum Operating Temperature +85°C | ||
Lifetime 2000h | ||
Lead Pitch 2.5mm | ||
Polarised Polar | ||
Leakage Current 4 μA | ||
Series SMQ | ||
Ripple Current 210mArms | ||
Tolerance ±20% | ||
Dissipation Factor 0.14% | ||
- COO (Country of Origin):
- JP
Downsized from current standard SMG series
Endurance : 2,000 hours at 85℃
Non solvent resistant type
RoHS2 Compliant
Endurance : 2,000 hours at 85℃
Non solvent resistant type
RoHS2 Compliant
