onsemi, 9.1V Zener Diode 5% 1 W Through Hole 2-Pin DO-41
- RS Stock No.:
- 805-0987
- Mfr. Part No.:
- 1N4739ATR
- Brand:
- onsemi
Available to back order for despatch 09/05/2024
Added
Price Each (In a Pack of 100)
£0.062
(exc. VAT)
£0.074
(inc. VAT)
| Units | Per unit | Per Pack* |
| 100 - 400 | £0.062 | £6.20 |
| 500 - 900 | £0.06 | £6.00 |
| 1000 - 4900 | £0.041 | £4.10 |
| 5000 - 9900 | £0.031 | £3.10 |
| 10000 + | £0.025 | £2.50 |
| *price indicative | ||
- RS Stock No.:
- 805-0987
- Mfr. Part No.:
- 1N4739ATR
- Brand:
- onsemi
Technical Reference
Legislation and Compliance
Product Details
Zener Diodes 1W, 1N4728A - 1N4758A Series, Fairchild Semiconductor
Zener Diodes, Fairchild Semiconductor
Specifications
Attribute | Value |
|---|---|
| Nominal Zener Voltage | 9.1V |
| Diode Configuration | Single |
| Number of Elements per Chip | 1 |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 1 W |
| Package Type | DO-41 |
| Zener Type | General Purpose |
| Zener Voltage Tolerance | 5% |
| Pin Count | 2 |
| Test Current | 28mA |
| Maximum Zener Impedance | 5Ω |
| Maximum Reverse Leakage Current | 10µA |
| Dimensions | 2.72 (Dia.) x 5.2mm |
| Maximum Operating Temperature | +200 °C |
| Minimum Operating Temperature | -65 °C |
