Vishay, 15V Zener Diode ± 2% 0.42 W SMT 3-Pin SOT-23

View all Zener Diodes
Bulk discount available

Subtotal (1 pack of 100 units)*

£2.90

(exc. VAT)

£3.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 11,100 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
100 - 900£0.029£2.90
1000 - 2400£0.026£2.60
2500 - 4900£0.025£2.50
5000 - 9900£0.019£1.90
10000 +£0.014£1.40

*price indicative

Packaging Options:
RS Stock No.:
180-8617
Mfr. Part No.:
BZX84C12-E3-08
Brand:
Vishay
Find similar products by selecting one or more attributes.
Select all

Brand

Vishay

Nominal Zener Voltage

15V

Diode Configuration

Single

Mounting Type

Surface Mount

Maximum Power Dissipation

0.42 W

Package Type

SOT-23

Zener Type

Small Signal

Zener Voltage Tolerance

± 2 %,± 5%

Pin Count

3

COO (Country of Origin):
CN

Vishay Zener Diode


The Vishay SOD-23 small signal Zener diode has a voltage rating of 12VDC and power rating of 300mW at 5% voltage tolerance. The Zener current rating of the diode is 0.1μA and reverse current rating is 0.1μA.

Features and Benefits


• ESD capability according to AEC-Q101: human body model > 8kV and machine model > 800V
• Lead (Pb) free component
• Operating junction temperature ranges between -55°C and 150°C
• Replace C in order code with B for ±2% tolerance
• Silicon planar Zener diode
• The Zener voltages are graded according to the international standard

Applications


• Voltage regulators
• Voltage stabilization

Certifications


• AEC-Q101 qualified
• Automotive Grade
• E24
• e3
• J-STD-020
• UL94 listed
