Deltron Panel XLR Connector, Straight, 50V ac Male, 3 Way, Silver Plating
- RS Stock No.:
- 180-6777
- Mfr. Part No.:
- 711-0300
- Brand:
- Deltron
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.
- RS Stock No.:
- 180-6777
- Mfr. Part No.:
- 711-0300
- Brand:
- Deltron
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Deltron | |
| Product Type | XLR Connector | |
| Number of Contacts | 3 | |
| Current | 15A | |
| Mount Type | Panel | |
| Orientation | Straight | |
| Colour | Black | |
| Connector Gender | Male | |
| Contact Plating | Silver | |
| Housing Material | Zinc Alloy | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -25°C | |
| Voltage | 50V ac | |
| Maximum Operating Temperature | 70°C | |
| Contact Material | Brass | |
| Contact Gender | Male | |
| Length | 30.6mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Deltron | ||
Product Type XLR Connector | ||
Number of Contacts 3 | ||
Current 15A | ||
Mount Type Panel | ||
Orientation Straight | ||
Colour Black | ||
Connector Gender Male | ||
Contact Plating Silver | ||
Housing Material Zinc Alloy | ||
Termination Type Solder | ||
Minimum Operating Temperature -25°C | ||
Voltage 50V ac | ||
Maximum Operating Temperature 70°C | ||
Contact Material Brass | ||
Contact Gender Male | ||
Length 30.6mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- GB
A range of panel mounting audio and video connectors incorporating many innovative features, compatible with all leading manufactures' cable sockets
Has an internal cut out which ensures a positive and secure socket retention
feature.
Generous solder buckets enable easier cable assembly as well as catering for
larger
conductive sizes.
Available in satin nickel or matt black finish, with either silver or gold plated
Contacts.
